DC motor controller module - four-channel - extension for Raspberry Pi Pico - Waveshare 19764
32.86 €
3811767 WSR-20548
5904422381622
Shipping 11-18 b.d.
You are interested in this product?
All about the product
DC motor controller in the form of a HAT add-on, designed for Raspberry Pi Pico. Made by Waveshare, it features a TB6612FNG chip for controlling up to four DC motors, and a PCA9685 chip – an accurate 12-bit PWM signal generator used to regulate motor speed. The add-on supports motors powered from 6 V to 12 V. The DC motor driver module also includes screw terminals that allow for easy and stable wire connections.
Main features:
- Compatible with Raspberry Pi Pico version
- Equipped with a connector compatible with Raspberry Pi Pico plugs
- Uses I2C bus for communication, supports 32 different I2C addresses by setting 5 address jumpers
- Contains a built-in PCA9685 chip, which is an accurate 12-bit PWM signal generator used to control motor speed
- Features an integrated TB6612FNG dual H-bridge motor controller with high performance
- Integrated 5 V regulator, output current up to 3 A, can be powered from a battery via the VIN terminal
- Supports motors from 6 V to 12 V
- With screw terminals for safe wire connections
- Designed for: Raspberry Pi Pico
- Add-on type: DC motor controller
- Control: 4 DC motors
- Motor operating voltage: from 6 V to 12 V (via VIN terminal)
- Current power: 3 A
- Logic level power voltage: 3.3 V
- PWM controller: PCA9685 chip
- Motor controller: TB6612FNG chip
- Interface: I2C bus
- Add-on dimensions: 65 x 56 mm
