iiyama TW1023ASC-B3P Signage Display
4042673 TW1023ASC-B3P
4948570126927
Shipping 5-7 days
Connectivity
The RJ45 (LAN) connector supporting Power over Ethernet technology (POE) allows to provide both data connection and power by a single cable, which simplifies installation in areas where many cables would interfere with the environment.
Android OS
Thanks to Android OS, you can easily customize the display to your needs by installing applications directly to it.
Build-in webcam, microphone and speakers
Making the screen a perfect solution for semi or fully automated reception solutions allowing businesses to track and manage visitor traffic at the front desk lobby without compromising on the safety and security of your staff, visitors and company assets.
iiSignage²
iiSignage² is our digital signage content management platform to easily show and control your content and to manage your displays in a secure way. The Content Management System (CMS) gives you total control of your messaging and advertising remotely and safely.
| Display diagonal | 25.6 cm (10.1") |
| HD type | HD |
| Display resolution | 1280 x 800 pixels |
| Native aspect ratio | 16:10 |
| Operating system installed | Android |
| RMS rated power | 3 W |
| Wi-Fi | Yes |
| Bluetooth | Yes |
| Product colour | Black |
| VESA mounting | Yes |
| USB 2.0 ports quantity | 2 |
| Touchscreen | Yes |
| Display number of colours | 16.7 million colours |
| Processor frequency | 2 GHz |
| Processor model | RK3568 |
| Processor cores | 4 |
| Internal storage capacity | 32 GB |
| Compatible memory cards | SD |
| Wi-Fi standards | 802.11a; 802.11b; 802.11g; Wi-Fi 4 (802.11n); Wi-Fi 5 (802.11ac) |
| Bluetooth version | 5.2 |
| USB port | Yes |
| USB connector type | USB Type-A; Micro-USB |
| USB version | 2.0/3.2 Gen 1 (3.1 Gen 1) |
| Weight | 800 g |
| Width | 255 mm |
| Depth | 30.5 mm |
| Height | 172 mm |
| Cables included | AC |
| Internal memory | 4 GB |
| Package width | 398 mm |
| Package depth | 398 mm |
| Package height | 223 mm |
| Package weight | 1.36 kg |
| Sustainability certificates | ErP |
| Power consumption (off) | 0.3 W |
| Quick start guide | Yes |
| Pallet gross width | 2.15 m |
| Pallet gross length | 100 cm |
| Pallet gross height | 120 cm |
| Products per pallet | 256 pc(s) |
| Purpose | Universal |
| Certification | CE, EAC, RoHS support, ErP, WEEE, REACH, UKCA |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| DC-in jack | Yes |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Card reader integrated | Yes |
| Power consumption (typical) | 18 W |
| Built-in speaker(s) | Yes |
| USB ports quantity | 4 |
| Input voltage | 12 V |
| Fingerprint resistant | Yes |
| Orientation | Horizontal/Vertical |
| Contrast ratio (typical) | 1000:1 |
| Viewing angle, horizontal | 160° |
| Viewing angle, vertical | 160° |
| Display diagonal (metric) | 25.5 cm |
| Operating system version | 13 |
| Cable management | Yes |
| Power consumption (standby) | 0.5 W |
| Display brightness | 450 cd/m² |
| Built-in microphone | Yes |
| Power supply type | External |
| Product design | Digital signage flat panel |
| Number of microphones | 1 |
| DVI port | No |
| Built-in processor | Yes |
| Processor manufacturer | Rockchip |
| On-board graphics card model | Mali-G52 MC1 |
| Panel type | IPS |
| Pixel pitch | 0.1692 x 0.1692 mm |
| DisplayPorts quantity | 0 |
| Response time | 25 ms |
| Built-in camera | Yes |
| PC Audio in | Yes |
| Suitable for indoor use | Yes |
| Internal memory | 32000 MB |
| Touchscreen technology | Projected capacitive system |
| Glass thickness | 1.25 mm |
| Number of simultaneous touchpoints | 10 |
| Megapixel (approx.) | 5 MP |
| Active display area (W x H) | 216.6 x 135.4 mm |
| Viewable size, horizontal | 21.7 cm |
| Viewable size, vertical | 13.5 cm |
| Operating hours (hours/days) | 24/7 |
| Surface hardness | 6H |
| Micro-USB ports quantity | 1 |
| Colour depth | 8 bit |
| Mini HDMI ports quantity | 1 |
| Power adapter included | Yes |
| RJ-45 ports quantity | 1 |
| Multi-touch | Yes |
| Compliance certificates | CE; RoHS; REACH; WEEE; UKCA; EAC |
