Fuj: tech GSM / UMTS / 3G / 4G / LTE / WiFi antenna
76.27 €
Monthly payment from 2,86 €
735293 BY0728
6416280455937
Goods will arrive at the Tallinn warehouse on 22.09.26
You are interested in this product?
All about the product
Powerful Log Periodic Antenna designed for two frequency bands. A common application is to strengthen data communication and improve data transfer rates. The antenna is supplied with a 10m low disturbance LRM200 cable with SMA male connector.
Features:
- For outdoor use
- Gain: 11 dBi logper periodic
- Low loss 10m cable LRM200
- Frequency Band: 698-960 / 1710-2700
- Polarization: horizontal beam 65/50 ° vertical beam 50/40 °
- Connection: SMA male
- Front / rear ratio ≥18 dB VSWR ≤1.5
- Impedance 50 Ω
- Maximum power 50 W
- Wind load 60 m / s
- Temperature range -40- + 70 ºC
- Size 445 x 265 × 65 mm
- Weight 0.6 kg maximum
Works without a separate adapter with Huawei B525, B535, B593, B315, B715, TP-LINK TL-MR6400, MR200, MR400, MR600, ZyXEL LTE3301, LTE33101 Plus, LTE3302, LTE3316 and LTE5366.
