Dahua Technology Router DAHUA AX18
60.44 €
Monthly payment from 2,46 €
5098669 AX18
6937552429239
Shipping 8-12 b.d.
You are interested in this product?
All about the product
DAHUA AX18 Router
Model: AX18
Key Features
- Wireless router AX18
- 6th generation wireless technology
- Wireless speed 1.8 Gb/s (574 Mbps@2.4 GHz, 1201Mb/s@5 GHz)
- Compatibility with IEEE 802.11 b/g/n/ac/ax standards
- Beamforming technology for better connection
- OFDMA and 1024-QAM
- Dual-band MU-MIMO
- Secure WiFi access (WPA/WPA2/WPA3)
- Guest Wi-Fi
- Parental control
Technical Specification
| WAN Port | 1×10/100/1000 Mb/s |
| LAN Socket | 3×10/100/1000 Mb/s |
| Reset Button | 1 |
| WPS Button | 1 |
| Power Consumption | <12 W |
| Memory | 128 MB Flash memory and 256 MB RAM |
| Indicator | PWR (Light Emitting Diode) |
| Wireless Standard | 2.4 GHz: 802.11 b/g/n/ax |
| 5 GHz: 802.11 a/n/a/ac/ax | |
| Performance | |
| Operating Frequency | 2,412–2,484 GHz |
| 5,150–5,850 GHz | |
| Wireless Transmission Speed | 2.4 GHz: 574 Mb/s |
| 5 GHz: 1201 Mb/s | |
| Channel Width | 20/40/80 MHz |
| Max. Output Power | 20 dBm ± 2 dBm |
| Antenna Gain | 2.4 GHz: 5 dBi (±0.5) |
| 5 GHz: 5 dBi (±0.5) | |
| Receiver Sensitivity | 2.4 GHz |
| 11n HT20_MCS0: -95 dBm | |
| HT20_MCS7 11N: -75 dBm | |
| HT40_MCS0 11N: -92 dBm | |
| HT40_MCS7 11N: -72 dBm | |
| HE20_MCS0 11ax: -95 dBm | |
| HE20_MCS11 11ax: -65 dBm | |
| HE40_MCS0 11ax: -92 dBm | |
| HE40_MCS11 11ax: -62 dBm | |
| 5 GHz | |
| 11 standard VHT80_MCS0: -89 dbm | |
| 11:VHT80_MCS9:-62 dbm | |
| HE80_MCS0 11ax: -89 dBm | |
| 11ax HE80_MCS11:-59 dBm | |
| Optimal Transmission Distance | 63 m (206.69 feet) |
| Channel | 2.4 GHz: 1-13 |
| 5 GHz: 36/40/44/48,52/56/60/64,149/151/153/157/161/165 | |
| Connected Wireless Terminals | 2.4 GHz: 32 |
| 5 GHz: 32 | |
| Function | |
| Encryption Mode | WPA-PSK mode |
| WPA-PSK/WPA2-PSK/WPA2-PSK/WPA3-SAE | |
| Management and Log | NTP; System Log |
| Software Update | Web/WiLynk application update |
| OFDMA | Yes |
| MU-MIMO | 2x2 |
| DHCP Protocol | Yes |
| Network Address Translator | Port-based binding |
| VPN | L2TP Protocol |
| PPTP Protocol | |
| QoS Function | Yes |
| DDNS | Yes |
| Parental Control | Yes |
| Firmware Management | Yes |
| General Information | |
| Power | 12 V DC, 1 A |
| Operating Temperature | From 0°C to 40°C (from 32°F to 104°F) |
| Storage Temperature | From –20°C to +70°C (from –4°F to 158°F) |
| Humidity | 10–90% (relative humidity), non-condensing |
| Total Weight | 0.73 kg (1.61 lbs) |
| Net Weight | 0.43 kg (0.95 lbs) |
| Package Dimensions | 309 mm × 298 mm × 61 mm (12.17" × 11.73" × 2.40") (L × W × H) |
| Product Dimensions | 252 mm × 155 mm × 178 mm (9.92" × 6.10" × 7.01" (L × W × H) |
| Electrostatic Discharge Protection | Air discharge: 8 kV |
| Contact discharge: 6 kV | |
| Lightning Protection | Common mode: 2 kV |
| Differential mode: 0.5 kV | |
| AX18 Package Includes | 1× Device |
| 1× Power Adapter | |
| 1x Patchcord | |
| 1× Quick Start Guide | |
| 1× Legal and Regulatory Information | |
