HDMI to LAN Adapter Spacetronik SPH-HLC11 KVM
5095692 5907100099598
Shipping 8-11 b.d.
All about the product
Main Information
The "Spacetronik SPH-HLC12T" HDMI to LAN KVM converter transmits 4K @ 30Hz HDMI UHD signal via CAT5e/6 network cable up to 120 meters in distance. The set includes a transmitter (TX) and a receiver (RX). It supports HDMI 1.4, HDCP 1.4, local loopback, IR control, a 3.5 mm audio jack, USB mouse, keyboard, and touch screen via USB. Low power consumption.
Application
Designed for large HDMI signal transmission over LAN networks. Compatible with 4K HDMI devices, supports IR control, USB mouse, and USB keyboard. Suitable for use in devices that require HDMI extension, such as offices, conference rooms, and surveillance systems.
Specification
Transmission and Interfaces
- CAT5e/CAT6 cable length between receiver and transmitter: 120 m
- HDMI input: 4K / 1080p / 720p / 576p / 576i / 480p / 480i
- HDMI output: 4K / 1080p / 720p / 576p / 576i / 480p / 480i
- Maximum bandwidth: 340 MHz
- Maximum transmission speed: 3 × 3.4 Gb/s
- Input video signal: 0.5 ~ 1.5 V
- DDC output signal: 5 V pp (TTL)
- HDMI input/output cable distance: 10 m (standard AWG26 HDMI cable)
- HDMI 1.4 / HDCP 1.4 support
- IR, USB support (mouse, keyboard, touch screen)
- 3.5 mm audio output jack (TX and RX)
Power Supply and Operating Conditions
- Power supply: AC input (50/60 Hz) 100–240 V; DC output 5 V / 1 A
- Maximum transmitter operating current: 350 mA
- Maximum receiver operating current: 200 mA
- Operating temperature: -15 °C to +55 °C
- Operating humidity range: 5 % to 90 % relative humidity (non-condensing)
Dimensions and Weight
- Dimensions (L × W × H): 107 × 105 × 27.3 mm
- Weight: shipping weight 499 g, receiving weight 494 g
