Power Supply - HiSmart 24V 25A 600W Switching Power Supply with Protections Black
74.05 €
Monthly payment from 2,81 €
5084770 9990000700820
Shipping 10-12 b.d.
You are interested in this product?
All about the product
HiSmart Power Supply 24V 25A 600W
24V switching power supply with a maximum output of 25A and a rated power of 600W. It features built-in protections against short circuits, overloads, and overvoltage, and operates efficiently with a cooler.
- Compact and lightweight design, ideal for space saving in electrical cabinets.
- High efficiency rating of 87%, ensuring reliable power delivery with minimal energy loss.
- Comprehensive protection features, including short circuit, overload, and overvoltage protections.
- Automatic temperature-controlled cooler for effective cooling and improved performance.
Features | |
|---|---|
| Product Type | Switching Power Supply |
| Model | 24V, 25A, 600W |
Specifications | |
| Input Voltage Range | AC 100–240 V |
| Input Frequency | 47-63Hz |
| Output Voltage | 24V DC |
| Adjustable Output Voltage Range | ±10% |
| Maximum Output Current | 25A |
| Rated Power | 600W |
| AC Current | 12A/110-120V, 5.5A/200-240V |
| Noise and Ripple Level | 300 mV p-p |
| Efficiency | 87% |
| Leakage Current | <3.5 mA / 240 V AC |
| Operating Temperature | -10°C to +50°C |
| Operating Humidity | 20%-90% RH |
| Dimensions | 215 x 115 x 50 mm |
| Weight | 0.9 kg |
Additional Information | |
| Cooling Method | Automatic temperature-controlled cooler |
| Protection Features | Short circuit, overload, overvoltage, overtemperature |
| Mounting | Suitable for electrical distribution and automation cabinets |
