Peladn G2E Docking Station (Silver) Thunderbolt 5

All about the product

„Peladn G2E Thunderbolt 5“ docking station (silver)

The „Peladn G2E Thunderbolt 5“ is an advanced docking station that significantly expands the capabilities of modern laptops and desktop computers. It offers up to 120 Gb/s bandwidth, supports two 8K monitors or a three-screen configuration, fast 140 W Power Delivery charging, a 2.5 G Ethernet port, and the ability to expand storage using an M.2 2280 PCIe 4.0 x4 drive. Other important advantages include smart RGB lighting and a wide array of 13 ports, allowing multiple devices to be connected simultaneously.

Exceptional data transfer speeds and 8K monitor support

The dock utilizes Thunderbolt 5 technology, ensuring up to 120 Gb/s asymmetric bandwidth and up to 80 Gb/s bidirectional symmetric bandwidth. Such high performance allows efficient management of multiple devices simultaneously, transferring large files, and using advanced applications that require fast connections between devices. The “Peladn G2E” also allows working with two 8K monitors or a configuration with three extended screens. With HDMI 2.1, DisplayPort 2.1, and Thunderbolt 5 ports, you can create a comprehensive workstation for creative work, programming, data analysis, or entertainment.

High resolution and smooth visuals

This docking station allows you to fully utilize the potential of modern high-resolution monitors with high refresh rates. Devices with Thunderbolt 5 can support one screen with 8K resolution at 60 Hz or 4K resolution at 240 Hz via Thunderbolt, HDMI 2.1, and DisplayPort 2.1 ports. When working with two monitors, both displays can show 8K resolution at 60 Hz or use two 4K monitors simultaneously at 240 Hz. On computers with Thunderbolt 4, the dock supports one 8K 60 Hz or 4K up to 240 Hz monitor via HDMI, as well as two monitors operating up to 2 × 4K 60 Hz resolution.

Storage expansion, high-speed networking, and 13 expansion ports

The dock features an M.2 2280 slot with a PCIe 4.0 x4 interface, allowing the installation of an additional SSD with a capacity of up to 8 TB. The integrated 2.5 G Ethernet RJ45 port ensures data transfer speeds of up to 2.5 Gb/s, which is 2.5 times the bandwidth of a standard gigabit Ethernet port. Users can also benefit from 13 expansion ports, including DisplayPort 2.1, HDMI 2.1, USB-A 3.2 Gen 2, Thunderbolt 5 ports, SD 4.0 and TF 4.0 card readers, and a headphone/microphone jack. This enables convenient connection of monitors, storage devices, audio equipment, and many other peripherals.

140 W charging and wide compatibility

Prior to connecting the Thunderbolt 5 port, it supports up to 140 W Power Delivery charging, allowing you to work and charge your laptop simultaneously with one cable. The dock is compatible with devices using Thunderbolt 5, Thunderbolt 4, USB4, and USB-C. It supports Windows 11 23H2 or newer versions and macOS 14.5 or newer versions. The manufacturer has also included a special mode that extends functionality for Mac mini computers with Apple Silicon M4 and M4 Pro chips.

Smart RGB backlighting

The integrated RGB strip allows you to customize the dock's appearance according to your preferences. The touch panel enables switching between various backlighting modes, including solid lighting and a breathing effect in multiple colors. If needed, the backlighting can also be completely turned off.
