Spacetronik Wall Mount Controller SPH-VW231
5048127 5903031026481
Shipping 8-11 b.d.
All about the product
Main Information
SPH-VW231 2x3 video wall controller. Supports 1 HDMI input, 2 USB 2.0 inputs, Ethernet input, microSD slot, and 6 HDMI outputs. Splits HDMI signal into 6 blocks and assigns it to 6 screens. Audio extraction to Toslink or 3.5 mm jack output. Supports multiple connection modes, cascading connection, Wi-Fi and DLAN. Plug and play, no software required.
Application
Designed for creating 2x3 video walls in professional installations. Built for use with LCD screens, projectors, and other HDMI compatible devices. Suitable for multi-screen systems, commercial, and educational environments.
Specifications
Specifications
Inputs and Outputs
- 1 HDMI input
- 2 USB 2.0 input ports
- 1 Ethernet input
- microSD slot
- 6 HDMI outputs
- Audio output: Toslink, 3.5 mm jack
Supported Formats and Modes
- HDMI input resolution: up to 3840x2160 / 60 Hz
- HDMI output resolution: up to 1920x1080 / 60 Hz
- Supported audio formats: DTS-HD, DTS, Dolby-AC3, PCM
- Wi-Fi, DLAN support
- Supports multiple connection modes, cascading
Technical Parameters
- Input cable length: 4K/30Hz up to 8 m (HDMI AWG26), 4K/60Hz up to 3 m (HDMI V2.0)
- Output cable length: up to 10 m (HDMI AWG26)
- Maximum operating current: 1.6 A
- Power supply: input AC 100-240V (50/60Hz), output 12V DC / 2A
- Operating temperature: from -10 °C to +55 °C
- Dimensions: 263 x 159 x 38 mm
- Weight: approximately 1300 g
