The product's shade and actual color may differ from what is shown in the picture, as the images are for illustrative purposes. The product description is general and may not include all the product's features.
Fireproof cable non-flammable armored Bitner 2x2x1.0mm (500 m) HTKSHekw FE180/Ph90 E90
768.92 €
Monthly payment from 20,70 €
5040688 5902956373373
Shipping 4-6 b.d.
You are interested in this product?
All about the product
- Temperature range:
- Fixed installation: -30°C up to 80°C
- During installation: -5°C up to 50°C
- Operating voltage: 225V
- Testing voltage: AC 1500 V DC 2250 V
- Insulation resistance (minimum): 500 MΩ*km
- Loop resistance at 20°C (maximum):
- 0.8 mm - 75 Ω/km
- 1.0 mm - 48 Ω/km
- 1.4 mm - 26.6 Ω/km
- 1.8 mm - 14.96 Ω/km
- 2.3 mm - 9.6 Ω/km
- 2.8 mm - 6.4 Ω/km
- Mutual capacitance at 1kHz (maximum):
- Unscreened cable: 120 nF/km
- Screened cable: 150 nF/km
- Inductance: 0.7 mH/km
- Min. bending radius: 10 x Ø
