Biostar A520MHP motherboard AMD A520 Socket AM4 micro ATX
59.00 €
Monthly payment from 2,42 €
5011462 A520MHP2.0
4712960688780
This product is no longer in stock
You are interested in this product?
All about the product
| Supported processor sockets | Socket AM4 |
| Processor socket | Socket AM4 |
| Processor manufacturer | AMD |
| Compatible processor series | AMD Ryzen 5000 Series |
| Compatible processor series | AMD Ryzen 4000 Series |
| Compatible processor series | AMD Ryzen 3000 Series |
| DirectX version | 12.0 |
| Parallel processing technology support | Not supported |
| HDCP | Yes |
| Motherboard chipset family | AMD |
| Motherboard chipset | AMD A520 |
| Motherboard form factor | micro ATX |
| Audio chip | Realtek ALC897 |
| Product colour | Black |
| Windows operating systems supported | Windows 11 x64 |
| Windows operating systems supported | Windows 10 x64 |
| Audio output channels | 7.1 channels |
| Supported memory clock speeds | 2400 |
| Supported memory clock speeds | 2933 |
| Supported memory clock speeds | 3600 |
| Supported memory clock speeds | 2667 |
| Supported memory clock speeds | 4400 MHz |
| Supported memory clock speeds | 3200 MHz |
| Supported memory clock speeds | 4266 |
| Supported memory clock speeds | 3800 |
| Supported memory clock speeds | 2133 |
| Supported memory clock speeds | 4133 |
| Supported memory clock speeds | 4000 |
| Maximum internal memory | 64 GB |
| Memory channels | Dual-channel |
| ECC compatibility | Non-ECC |
| Memory slot pin count | 288 |
| Maximum internal memory per slot | 32 GB |
| Supported memory types | DDR4-SDRAM |
| Memory slots type | DIMM |
| Number of memory slots | 2 |
| Supported memory clock speed (max) | 4400 MHz |
| Width | 190 mm |
| Depth | 235 mm |
| LAN controller | Realtek RTL8111H |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Ethernet interface type | Fast Ethernet |
| Ethernet interface type | Gigabit Ethernet |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
| USB 2.0 connectors | 2 |
| Number of SATA III connectors | 4 |
| ATX Power connector (24-pin) | Yes |
| Number of COM connectors | 1 |
| CPU fan connector | Yes |
| EPS power connector (8-pin) | Yes |
| Front panel connector | Yes |
| Front panel audio connector | Yes |
| Number of EPS power connectors (8-pin) | 1 |
| Number of CPU fan connectors | 1 |
| Audio connector | Yes |
| BIOS type | UEFI |
| Clear CMOS jumper | Yes |
| Drivers included | Yes |
| Cables included | SATA |
| RAID levels | 10 |
| RAID levels | 0 |
| RAID levels | 1 |
| Supported storage drive interfaces | PCI Express 3.0, SATA III |
| Supported storage drive types | HDD & SSD |
| RAID support | Yes |
| Number of storage drives supported | 5 |
| USB 2.0 ports quantity | 4 |
| HDMI ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| USB connector type | USB Type-A |
| Microphone in | Yes |
| VGA (D-Sub) ports quantity | 1 |
| Headphone outputs | 3 |
| PS/2 ports quantity | 1 |
| PCI Express x1 (Gen 3.x) slots | 2 |
| PCI Express x16 (Gen 3.x) slots | 1 |
| Number of M.2 (M) slots | 1 |
| 1st M.2 largest key size | 2280 |
| 1st M.2 highest PCI Express generation | 3.0 |
