TOOLKITRC Automatic Lead Acid / LiFePO4 Battery Charger, 24V 10A

All about the product

Automatic smart battery charger with integrated charging management system for 24V lead-acid and LiFePO4 batteries. It is designed to charge and maintain batteries of various 24V systems. Automatically detects battery status and selects the appropriate charging mode.

Features:
Suitable for 24V batteries: can be used in various vehicles and devices.
Supported battery types: lead-acid (STD, AGM, GEL, CAL), lithium iron phosphate (LiFePO4).
Automatic charging: the device automatically adjusts the charging current and voltage level according to the battery's status.
Automatic smart charging algorithm with a 3-stage charging mode: the charger first charges the battery with a constant current, then with a constant voltage, and finally switches to maintenance mode. This type of charging ensures efficient, safe charging, reduces the risk of overcharging, and helps extend battery life.
Battery type selection button allows for convenient selection of the appropriate mode based on the battery used.
LED indication shows the selected battery type and charger operating status.
Maximum charging current of 10A, making the device suitable for both charging and battery maintenance.
The package includes clamps for easy connection to the battery.
Integrated protections: against reverse polarity, overvoltage, and overheating, ensuring the charger protects both the battery and the device itself.
Wide power voltage range allows the device to be used in various conditions.
Easy to use. Simply connect the battery to the charger, select the appropriate battery type, and turn on the power – the device carries out the automatic charging process.
Compact design ensures convenient use and storage.
Wide application: suitable for car, motorcycle, boat, camper, security system, and other 24V system batteries.
Advantages: easy to use, automatic operation, efficient battery charging, and longer battery life.

Specifications:
Input voltage: 180-240V AC.
Charging current (Imax): 10 A.
Input current: 1.56 A.
Output current: 0-10 A.
Supported battery types: STD, AGM, GEL, CAL, LiFePo4.
Charging voltage: 28.8 V (STD); 28.4 V (GEL); 30.0 V (CAL); 29.2 V (AGM); 29.2 V (LiFePO4).
Maintenance charging voltage: 26.8 V (STD); 26.4 V (GEL); 27.6 V (CAL); 27.2 V (AGM); (LiFePO4 not applicable).
Standard "boost" charging voltage: 28.4 V ±0.2V.
Standard maintenance charging voltage: 27.6 V ±0.2V.
Display: LED.
Efficiency (typical): 85%.
Operating temperature: 0°C ~ +60°C.
Operating humidity: 20-90% RH (non-condensing).
Dimensions: 156 mm x 222 mm x 87 mm.
Weight: ~1.5 kg
Color: black.


Warranty: 24 months.
