TOOLKITRC Automatic Lead Acid / LiFePO4 Battery Charger, 24V 20A

All about the product

Automatic smart battery charger with integrated charging management system for 24V lead-acid and LiFePO4 batteries. It is designed to charge and maintain batteries for various 24V systems. Automatically detects the battery condition and selects the appropriate charging mode.

Features:
Suitable for 24V batteries: can be used in various vehicles and devices.
Supported battery types: lead-acid (STD, AGM, GEL, CAL), lithium iron phosphate (LiFePO4).
Automatic charging: the device regulates charging current and voltage level based on the battery condition.
Intelligent automatic charging algorithm with 3-stage charging mode: the charger first charges the battery with constant current, then with constant voltage, and finally switches to maintenance mode. This charging method ensures efficient, safe charging, reduces the risk of overcharging, and helps prolong battery life.
Battery type selection button allows convenient selection of the appropriate mode based on the battery used.
LED indication shows the selected battery type and charger operating status.
Maximum charging current of 20A, making the device suitable for both charging and battery maintenance.
The kit includes clamps for easy connection to the battery.
Integrated protections: against reverse polarity, overvoltage, and overheating, thus the charger protects both the battery and the device itself.
Wide input voltage range allows the device to be used under various conditions.
Easy to use. Just connect the battery to the charger, select the appropriate battery type, and turn on the power – the device will perform the automatic charging process.
Compact design ensures easy use and storage.
Wide application: suitable for batteries in cars, motorcycles, boats, campers, security systems, and other 24V systems.
Advantages: easy to use, automatic operation, efficient battery charging, and longer battery lifespan.

Specifications:
Input voltage: 180-240V AC.
Charging current (Imax): 20 A.
Input current: 3.14 A.
Output current: 0-20 A.
Supported battery types: STD, AGM, GEL, CAL, LiFePo4.
Charging voltage: 28.8 V (STD); 28.4 V (GEL); 30.0 V (CAL); 29.2 V (AGM); 29.2 V (LiFePO4).
Maintenance charging voltage: 26.8 V (STD); 26.4 V (GEL); 27.6 V (CAL); 27.2 V (AGM); (LiFePO4 not applicable).
Standard "boost" charging voltage: 28.4 V ±0.2V.
Standard maintenance charging voltage: 27.6 V ±0.2V.
Display: LED.
Efficiency (typical): 85%.
Operating temperature: 0°C ~ +60°C.
Operating humidity: 20-90% RH (non-condensing).
Dimensions: 266x182x87 mm.
Weight: ~1.9 kg
Color: black.


Warranty: 24 months.
