VL53L3CX time-of-flight, distance and ambient light sensor I2C, 500cm, Pololu 3416
5005751 AN-19102
5904422308544
Shipping 8-15 b.d.
All about the product
Digital sensor for time-of-flight and ambient light measurement. The measurement range is from 1 cm to 500 cm, with a 1 mm resolution. Communication is done via the I2C (TWI) bus and powered by 2.6–5.5 V. The module does not provide direct distance measurement - it outputs data in the form of a histogram that can be processed using algorithms provided by ST. The sensor includes passive components necessary for proper operation. The connections are popular gold pin connectors, allowing the sensor to be wired or connected directly to a breadboard.
Specifications:
- Supply voltage: 2.6 to 5.5 V
- Current consumption: 15 mA
- Interface: I2C (TWI)
- Interface address: 0x52
- Minimum measuring range: 1 cm
- Maximum measuring range: up to 500 cm
- Resolution: 1 mm
- Emitted wavelength: 940 nm
- Field of view (FOV): 25°
- Operating temperature range: from -20 °C to 85 °C
- Package: lead-free LGA
- Module dimensions: 13 x 18 x 2 mm
- Weight: 0.5 g
- Ambient light and distance sensor
- Straight gold pin socket 1x7 contacts
- Angular gold pins 1x7 contacts
