TOOLKITRC Automatic Lead Acid / LiFePO4 Battery Charger, 12V 10A

All about the product

Automatic smart battery charger with integrated charging management system for 12V lead-acid and LiFePO4 batteries. It is designed to charge and maintain various 12V system batteries. Automatically detects the battery status and selects the appropriate charging mode.

Features:
Suitable for 12V batteries: can be used in various vehicles and devices.
Supported battery types: lead-acid (STD, AGM, GEL, CAL), lithium iron phosphate (LiFePO4).
Automatic charging: the device regulates the charging current and voltage level according to the battery status.
Automatic smart charging algorithm with 3-stage charging mode: the charger first charges the battery with constant current, then constant voltage, and finally switches to maintenance mode. This type of charging ensures efficient, safe charging, reduces the risk of overcharging, and helps extend battery life.
The battery type selection button allows easy selection of the appropriate mode according to the battery used.
LED indication shows the selected battery type and charger operating status.
Maximum charging current 10A, making the device suitable for both charging and battery maintenance.
Charging voltage: boost mode 14.6 V ±0.2 V, maintenance mode 13.8 V ±0.2 V.
The package includes clamps for easy connection to the battery.
Integrated protections: against reverse polarity, overvoltage, and overheating, thus the charger protects both the battery and the device itself.
Wide power input voltage range allows the device to be used in various conditions.
Easy to use. Just connect the battery to the charger, select the appropriate battery type, and turn on the power – the device executes the automatic charging process.
Compact design ensures convenient use and storage.
Wide application: suitable for car, motorcycle, boat, camper, security systems, and other 12V system batteries.
Advantages: easy to use, automatic operation, efficient battery charging, and longer battery lifespan.

Specifications:
Input voltage: 180-240V AC.
Charging current (Imax): 10 A.
Frequency: 47-63Hz.
Input current: 0.78 A.
Output current: 0-10 A.
Supported battery types: STD, AGM, GEL, CAL, LiFePO4.
Charging voltage: 14.4 V (STD); 14.2 V (GEL); 15.0 V (CAL); 14.8 V (AGM); 14.6 V (LiFePO4).
Maintenance charging voltage: 13.4 V (STD); 13.2 V (GEL); 13.8 V (CAL); 13.8 V (AGM); (LiFePO4 not applicable).
Standard "boost" charging voltage: 14.6V ±0.2V.
Standard maintenance charging voltage: 13.8V ±0.2V.
Display: LED.
Efficiency (typical): 85%.
Operating temperature: 0°C ~ +60°C.
Operating humidity: 20-90% RH (non-condensing).
Dimensions: 156.1 mm x 182 mm x 87 mm.
Weight: ~1.2 kg
Color: black.


Warranty: 24 months.
