Hormann Lineamatic P 868Mhz BiSecure set for sliding gates up to 500 kg
5000257 4554309
4042533660708
Shipping 8-12 b.d.
All about the product
„Hormann Lineamatic P 868Mhz BiSecure“ kit for sliding gates, 500 kg
Purpose
The „Hormann Lineamatic“ kit (4554309) is designed for light sliding gates with a maximum weight of 500 kg and a maximum length of 8 meters. It is recommended that the gates weigh no more than 400 kg.
The „Hörmann“ gate drive systems are safe at every stage of opening and closing. The forces generated by the drives are tested by TÜV and certified for various gate sizes and installation situations according to PN EN 13241-1 standard. They ensure quiet and safe operation of the gates. The gates open smoothly and stop gently when closing. This solution protects both the gates and the drive mechanism and, most importantly, does not obstruct anyone.
A distinguishing feature of the „LineaMatic“ sliding gate kit is the compact, vertically adjustable housing made of die-cast zinc and glass-fiber reinforced plastic, as well as a reliable electronic system.
Technical Specifications:
- Power Supply Voltage: 230–240 V, 50 Hz
- Motor: with a reducer, powered by 24 V direct current
- Maximum Gate Weight (rail gates with bottom guide beam / self-supporting gates): 500 kg / 400 kg
- Maximum Gate Height: 2000 mm
- Maximum Number of Gate Cycles per Day: 40
- Housing Material: zinc casting and weather-resistant plastic
- Operating Temperature Range: from -20 °C to +60 °C
- Protection Class: IP44
- Magnetic Limit Switch: yes
- Automatic Closing Function: yes
- Gate Function: yes
- Number of Connectable Safety Devices: 3
