All about the product

Canon EOS R5 Mark II Body

Main Features

• 45 MP full-frame back-illuminated stacked CMOS sensor

• DIGIC Accelerator + DIGIC X image processors

• Canon RF lens mount

• Up to 30 frames per second shooting with electronic shutter

• 8K RAW and 4K up to 120p professional video recording

• Dual Pixel CMOS AF II autofocus system with AI object recognition

• 8.5 stops image stabilization (IBIS, with compatible RF lenses)

• Dual memory card slot: CFexpress Type B + SD UHS-II

• Wi-Fi 6E and Bluetooth wireless connectivity

Sensor

• Type: Full Frame Back-Illuminated Stacked CMOS

• Effective resolution: 45 MP

• Total pixel count: 50.3 MP

• Sensor dimensions: 36 × 24 mm

Image Processor

• DIGIC Accelerator

• DIGIC X

Lens Compatibility

• Canon RF lenses

• Canon RF-S lenses (1.6× crop)

• Canon EF and EF-S lenses using EF-EOS R adapter

Autofocus

• Dual Pixel CMOS AF II

• Detection of people, animals, and vehicles

• Eye, face, head, and body tracking

• Focus sensitivity down to EV -7.5

Shooting Performance

• Up to 30 fps with electronic shutter

• Up to 12 fps with mechanical shutter

• Support for RAW, C-RAW, HEIF, and JPEG files

Image Stabilization

• 5-axis integrated IBIS

• Up to 8.5 EV stabilization efficiency with compatible RF lenses

Video Recording

• 8K RAW

• 8K DCI/UHD

• 4K DCI/UHD up to 120 fps

• Full HD up to 240 fps

• Canon Log 2 / Canon Log 3

• HDR PQ

• XF-HEVC and XF-AVC recording formats

• 10-bit 4:2:2 recording

• ProRes RAW support via HDMI

Viewfinder

• OLED electronic viewfinder

• 5.76 million dots

• 0.76× magnification

Display

• 3.2" tiltable touchscreen LCD

• 2.1 million dots

Memory Cards

• 1 × CFexpress Type B

• 1 × SD UHS-II

Connectivity

• USB-C

• HDMI

• Microphone input

• Headphone jack

• Wi-Fi 6E (2.4 / 5 / 6 GHz)

• Bluetooth

Battery

• Canon LP-E6P

• Compatible with LP-E6NH and LP-E6N

Dimensions and Weight

• Dimensions: 138.5 × 101.2 × 93.5 mm

• Weight (body only): approximately 656 g

• Weight with battery and CFexpress card: approximately 746 g

Package Contents

• Canon EOS R5 Mark II camera body

• LP-E6P battery

• LC-E6E charger

• Strap

• Body cap

• User documentation
