Spacetronik Metal Case TPR-6W v3 Cabinet 540x420x180
4165210 5902188044690
Shipping 8-11 b.d.
All about the product
Main Information
The TPR-6W v3 surface-mounted metal housing is designed for installing and securing devices. It features knock-out cable entry openings, ventilation openings, and mounting holes for hanging. The package includes a lock with two keys and a 6 mm plywood mounting plate. Smooth front and sides, reinforced hinges with a pin.
Application
Intended for mounting electrical and electronic devices. Designed for surface mounting in areas requiring device protection. Compatible with systems that require ventilation and easy cable routing.
Specifications
Specifications
Dimensions and Material
- Width 540 mm
- Height 420 mm
- Depth 180 mm
- Sheet thickness 0.8 mm
- Material: powder-coated steel
- Mounting plate made of 6 mm waterproof plywood
Finish and Color
- White color
- Color code RAL 9003
- Smooth front and sides, without visible welding seams
Equipment and Features
- Removable type cable entries (top/bottom)
- Ventilation openings (top/bottom)
- Mounting holes for hanging
- Patented lock with two keys
- Reinforced hinges with removable pin
