Dahua Technology SG4010-2F Managed L2 Gigabit Ethernet (10/100/1000) Black
86.44 €
Monthly payment from 3,13 €
4033707 DH-SG4010-2F
6923172597670
Shipping 2-3 b.d.
You are interested in this product?
All about the product
Equipped with a high performance switching engine, the 8 Port All- Gigabit Managed Switch performs optimally. It has low transmission delay, large buffer and is highly reliable. It also has a strong switchingcapability and optimizes transmission performance when accessing Ultra HD videos. With its full metal design and fanless design, the device has great heat dissipation and is low power consumption, working
in environments ranging from –10°C to 55°C (+14°F to +131°F). With protection against overvoltage, EMC and overcurrent from power input terminals, the switch effectively resists interference from static electricity, lightning, and pulses. It also offers a variety of services, supporting IGMP Snooping, Link Aggregation, QoS, LLDP, STP/RSTP and various web and network management software based on SNMP.
Link Layer Discovery Protocol (LLDP)
Enables network devices to advertise their information mutually, al- lowing you to conveniently monitor and manage devices in the local topology. This makes it easy for administrators to effectively perform
troubleshooting.
Quality of Service (QoS)
Uses mechanisms designed to control bandwidth, delay, jitter, and loss to ensure the performance of services when the capacity is limited.
Spanning Tree Protocol (STP)
Uses algorithms that calculate the best loop-free path through a Layer 2 network while providing path redundancy to prevent the occurrence of broadcast storms and enhance the stability of operations and services.
Link Aggregation
Combines multiple physical links into one virtual channel for dynamic redundancy and load balancing, ensuring that the connection remains stable.
IGMP Snooping
Listens to multicast traffic, and solely forwards information to regis- tered clients based on the multicast forwarding table. This ensures the safety of information and improves network efficiency.
Fanless Design
The fanless design reduces noise, enhances user experience, reduces mechanical losses and improves service life to a certain extent.
Network | |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.1x, IEEE 802.1Q, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1p, IEEE 802.3z |
| Flow control support | Yes |
| Ethernet LAN data rates | 10, 100, 1000 |
| Full duplex | Yes |
| Multicast support | Yes |
| Jumbo frames support | Yes |
| Jumbo frames | 9000 |
| Number of VLANs | 4000 |
Management features | |
| Web-based management | Yes |
| Reset button | Yes |
| Quality of Service (QoS) support | Yes |
| Cloud-managed | No |
Security | |
| MAC address table | 8000 entries |
| Access Control List (ACL) | Yes |
| IGMP snooping | Yes |
Protocols | |
| Management protocols | SNMP V1/V2C/V3 |
Design | |
| LED indicators | Yes |
| Product colour | Black |
| Housing material | Steel |
| Wall mountable | Yes |
Features | |
| Mean time between failures (MTBF) | 2322286.99 h |
Power | |
| Power over Ethernet (PoE) | No |
Operational conditions | |
| Operating temperature (T-T) | -10 - 55 °C |
| Operating relative humidity (H-H) | 5 - 95% |
Weight & dimensions | |
| Width | 104 mm |
| Depth | 240 mm |
| Height | 28 mm |
| Weight | 640 g |
Packaging data | |
| Package width | 240 mm |
| Package depth | 316 mm |
| Package height | 82 mm |
| Package weight | 1.04 kg |
Other features | |
| Input current | 1 A |
| Rack mounting | No |
Technical details | |
| Compliance certificates | CE |
Sustainability | |
| Sustainability compliance | Yes |
