Lower connection radiator Purmo CV 33, 600-1400

329.00 €
Monthly payment from 9,37 €
3834976

F073306014011300

5907814709295

Shipping 10-14 b.d.

You are interested in this product?
(Read terms of service)

All about the product

Bottom connection radiator with thermostat element


Top quality product
Three profiled plates, three convectors
Height from 300 mm to 900 mm
Length from 400 mm to 3000 mm
Power from 539W to 9780W (75º/65 º /20 º )
Bottom connection, standardly from the right
Installed thermostat element
Includes wall brackets, blind and guide

Purmo Ventil Compact

The compact radiator is a classic panel radiator that meets the highest quality and efficiency requirements. While all pipes are visible in traditional radiators, the covers on the top and sides of compact radiators give them a pleasant and attractive appearance. The selection of models is as diverse as all our panel radiators.

Compact radiators can be of several different types, which you can perfectly adapt to your room. The Ventil model is a variant of the classic compact radiator. In this radiator, all pipes and valves are hidden inside the radiator, making it look subtle and uncluttered.

Technical data

Universal PURMO "Ventil Compact" radiators with profiled plates and convection elements, with side covers and top grilles. Two bottom and four side connection pipes, threaded internally G ½", allow for bottom connection, and if necessary, side connection. The radiator comes with an "Oventrop" primary control thermostat valve.

  • Material: high-quality stamped non-alloy rolled steel sheet FePO 1 according to EN 10130
  • Vertical water channel pitch: 33.3 mm
  • Connection pipes: 2 x G ½ " bottom connection on the right (left - on request), 4 x G ½ " side connection
  • Working pressure: 10 bar
  • Maximum temperature: 110 °C
  • Test pressure: 13 bar
  • Color: white RAL 9016, other RAL palette colors - on request
  • Accessories: mounting elements, blind, air vent (included)
