C-Back Driver HAT - extension with servo controller - STM32F0 - designed for M5StickC M5Stack development module
19.47 €
3825800 AN-19422
5904422363710
Shipping 11-18 b.d.
You are interested in this product?
All about the product
C-Back Driver HAT is an extension for M5StickC and M5StickC Plus. It is based on the STM32F030F4P6 chip, allowing control of up to 4 servos via PWM. It uses an I2C interface with address 0x38. It can be used to read general logic levels and analog ADC input signals. Additionally, it has two holes compatible with the LEGO standard, allowing you to easily attach the module to various surfaces.Key features:
- Used in robotics control applications
- Used as a servo control element
- 4 channels allow simultaneous control of four servo systems
- Supported programming platforms: Arduino
- With two holes that meet the LEGO standard
- Add-on for M5StickC and M5Stick Plus development modules
- Type: servo controller
- Number of integrated controllers: 4
- GPIO and I2C extensions
- Operating voltage: from 3.3 V to 5 V
- Operating current: 15 mA
- Interface: I2C bus
- Interface address: 0x38
- Module dimensions: 23.7 x 49.2 x 21 mm
- Weight: 9 g
- C-Back Driver HAT module - add-on with servo controller
- Mounting elements:
- M2 x 5 screws - 2 pcs
- Allen wrench
