Dfrobot Water Turbine Generator 5V
21.45 €
3767931 AN-09537
5904422338213
Shipping 7-9 b.d.
You are interested in this product?
All about the product
Water turbine generator with a 5 V DC output that can be used directly as a power source for Arduino. Eco-friendly energy, works with a lithium battery charger as backup power. This water turbine generator can be used in various hydro energy generator applications, such as smart faucets, sensor faucets, shower room lighting systems, etc. The maximum output current is up to 150 mA, which is sufficient for many simple operations.
Specifications:
- Operating pressure: up to 1 MPa
- Test pressure: up to 0.6 MPa
- Flow range: 2.5–20 l/min - pressure 0.05–0.2 MPa
- Output voltage: DC 5 V
- Output current: from 0 to 150 mA
- Minimum starting flow voltage: constant 2.5 V current 3.5 l/min
- Temperature range: from 0 to 80 °C - maximum ambient temperature can be 100 °C, but not longer than 30 minutes
- Storage temperature: from -25 °C to 65 °C
- Battery not included
