DFRobot Gravity Infrared CO2 Sensor 4.5 ~ 5.5V DC 0 ~ 50000ppm ± (50ppm + 5%) 0 ~ 50 ℃

139.00 €
Monthly payment from 4,48 €
3752160

AN-08110

5904422375638

Shipping 11-18 b.d.

You are interested in this product?
(Read terms of service)

All about the product

DFRobot company's Gravity infrared CO2 sensor, designed to measure CO2 concentration in the air in the range of 0~50000ppm. UART communication interface. Perfect for use with most microcontrollers.

Specifications:

Gas type: CO2

Operating voltage: 4.5 ~ 5.5V DC

Operating current: <85mA

Signal transmission type: UART

CO2 measurement range: 0 ~ 50000ppm

CO2 measurement accuracy: ± (50ppm + 5%)

Warm-up time: 3min

Response time: T90 < 30s

Operating temperature: 0 ~ 50 ℃

Operating humidity: 0 ~ 95% RH

Lifespan: >5 m

Dimensions: 21 * 27.11 mm/ 0.83 * 1.06 inc

Weight: 42g

Additional information:

WIKi

Other documents


Package contents:

UART infrared CO2 sensor probe (0-50000ppm) x1

Sensor replacement board x1

6-Pin sensor cable x1

PH2.0 Gravity UART cable x1

XH2.54 4-Pin connector x1
