Aneng XL830L multimeter - LCD digital multimeter with backlight
3749735 ABC-21064
5904384760923
Shipping 9-16 b.d.
All about the product
XL830L universal meter - LCD digital multimeter
XL830L is a convenient and inexpensive universal meter, perfect for workshops, service, or automotive use. It allows measuring high AC/DC voltage ranges and small DC currents. With it, we can measure transistor resistance, diode forward voltage, circuit continuity, or hFE. Multimeters come in various specifications.
XL830L – Features- Circuit continuity check
- Resistance measurement
- Diode forward voltage measurement
- DC current measurement
- DC and AC voltage measurement
- Transistor measurement
- Backlight
- Result memory
DCV
- 200 m/2/20/200 [V] +/-(0.8 %+/- 2)
- 600 V +/-(0.8 %+/- 2)
ACV
- 200 V +/-(0.8 %+3)
- 600 V +/-(1.2 %+3)
DCA
- 2mA/20mA +/-(1.2 % +/-2)
- 200 mA +/-(1.4 % +/-2)
- 10A +/- (2 % +/-2)
OHM
- 200 ohms +/-(1.0 %+/-2)
- 2k/20k/200k/2M[ohms] +/-(0.8 %+/-2)
- Transistor test: yes
- Auto power off: no
- Diode test: yes
- Circuit continuity alarm: yes – audible signal
- LCD display: yes
- HOLD function – measurement recording
- Display backlight function
- Battery: 9V 6F22
- Display range: 1–999
- Display size: 19x40 mm
- Dimensions: 140x70x33mm
Designed according to IEC-1010 standard for electronic measuring instruments with CAT II / CAT III overvoltage and pollution category 2.
Included- Brand new XL830L digital meter
- Test lead set
- Instructions in English
