OEM LCD screen 4x20 characters blue + I2C LCM1602 converter
22.31 €
3696457 AN-02640
5904422331061
Shipping 11-18 b.d.
You are interested in this product?
All about the product
Popular character and digital LCD display, powered by 5 V. It can display 80 characters in four rows of twenty columns. The I2C converter is soldered, so only two lines - SDA and SCL - are needed to control the display. You can control the text display, backlight, and turn it on or off at any time via the bus from Arduino. There is also a potentiometer on the board to adjust the contrast.
Specifications:
- LCD display 4x20 characters
- Character color: white
- Backlight: blue
- Module size: 98 x 60 mm
- Distance between holes: 93 x 55 mm
- I2C bus converter
- No pull-up resistors for I2C bus lines (switchable Arduino)
- Converter based on PCF8574 chip
- Soldered potentiometer for contrast adjustment
- Backlight control is possible via I2C bus
