UNINTERRUPTED POWER SUPPLY WITH BATTERY MODULE COVER-CORE-10K/3.5 10000 VA COVER
UNINTERRUPTED POWER SUPPLY WITH BATTERY MODULE COVER-CORE-10K/3.5 10000 VA COVER
UNINTERRUPTED POWER SUPPLY WITH BATTERY MODULE COVER-CORE-10K/3.5 10000 VA COVER
UNINTERRUPTED POWER SUPPLY WITH BATTERY MODULE COVER-CORE-10K/3.5 10000 VA COVER
UNINTERRUPTED POWER SUPPLY WITH BATTERY MODULE COVER-CORE-10K/3.5 10000 VA COVER

The product's shade and actual color may differ from what is shown in the picture, as the images are for illustrative purposes. The product description is general and may not include all the product's features.

UNINTERRUPTED POWER SUPPLY WITH BATTERY MODULE COVER-CORE-10K/3.5 10000 VA COVER

2 458,99 €
2 436,23 €
Monthly payment from 63.63
3663594

5902887094637

Shipping 1-14 b.d.

Quantity
You are interested in this product?
(Read terms of service)
Power supply type : Online
Active power : 10000W
Apparent power : 10000 VA
Input voltage : 208 V / 220 V / 230 V / 240 V AC
Input frequency : 50 / 60 Hz @ -20% / +20%
Output voltage : 208V / 220V / 230V / 240V AC (pure sine wave)
Power factor : 1
Output frequency : 50 / 60Hz ± 0.05Hz
Tension adjustment :
Frequency regulation :
Charging time (up to 90% level) : 4 hours
Battery : 1 battery module: 20 x 12V/9Ah
Estimated battery life : 1 battery module (20 x 12V/9Ah):
  • 28 minutes - 25% load,
  • 10.7 minutes - 50% load,
  • 5.7 minutes - 75% load,
  • 3.5 minutes - 100% load
  • Number of outputs : Terminal strip - possibility to connect an external strip with C13/C19/Schuko type sockets
    Management software : ViewPower
    Protective measures :
  • From short circuit
  • From overloads
  • Overload protection
  • discharge protection
  • Initial voltage filtering
  • REPO (Remote Emergency Power Off) port
  • Working status indication :
  • LCD display: operating mode, battery charge level, input/output voltage, frequency, load, overload indicator, alarm,
  • LED diodes: Bypass, LINE, Battery, Error,
  • Audible alarm
  • Main features :
  • The device has a rotating screen
  • Automatic restart when mains power returns
  • Automatic bypass
  • The COLD START function is for manual battery start-up
  • Battery power and maintenance control.
  • RS-232 port, USB port - Access from PC
  • SNMP - Network card location
  • Remote control - ViewPower application (included)
  • Inverter/converter (ensures full voltage stabilization) (PWM)
  • Parallel operation
  • Can be mounted in a 19" rack cabinet
  • Purpose :
  • Surveillance systems
  • data centers
  • network, servers, workstations
  • industrial equipment
  • Body type : 2 in 1 (Rack / Tower)
    Operating temperature/relative humidity : 0 °C ... 45 °C / 0 % ... 95 % (non-condensing)
    Weight :
  • 16.2 kg - UPS
  • 67.4 kg - battery module
  • Dimensions :
  • 438 x 665 x 88 mm; RACK 19", 2U - UPS
  • 438 x 635 x 133 mm ; RACK 19", 3U - battery module
  • Manufacturer / Brand : COVER
    Warranty : 2 years
