Fermion - ToF distance sensor TMF8801 - 2.5m - I2C - DFRobot SEN0430
29.00 €
3562844 AN-20676
5904422382186
Shipping 11-18 b.d.
You are interested in this product?
All about the product
DFRobot Fermion module with TMF8801 ToF distance sensor, which can measure 2-10 cm in the proximity range and 10-250 cm in the distance, with an accuracy of ± 5%. The sensor measures the distance based on the time difference between light pulses. It detects objects regardless of their color, reflectivity and object texture. The module uses an I2C interface and is powered from 2.7 V to 3.3 V.Main features:
- 21° FOI, detects objects closest to the center
- Measuring range from 20 mm to 2500 mm
- Measures in well-lit and dark environments with ± 5% accuracy
- Built-in histogram to compensate for dirt and streaks on the cover glass
- 940nm VCSEL Class 1 Eye Safety
- Low energy consumption:
- up to 940 μA at 10 Hz (close-up mode)
- Up to 26 mA at 60 Hz (distance and proximity mode)
- Up to 0.26 μA in sleep mode (EN = 0)
- Supply voltage: 2.7 V to 3.3 V
- Operating current: 1.5 mA
- Proximity detection range: 20 mm to 100 mm
- Distance detection range: 100 mm to 2500 mm
- Operating temperature: -30 °C to 60 °C
- Interface: I2C, 8-pin 2.54 mm
- Mounting hole size: 2 mm
- Mounting hole spacing: 17 mm
- Dimensions: 21 x 14.5 mm
