COUGAR CGR PR-1200 power supply unit 1200 W 20+4 pin ATX Silver
239,00 €
Monthly payment from 7.05 €
3475920 31PL120001P01
4710483772351
2026-07-29
You are interested in this product?
COUGAR will present the first Platinum efficiency PSU Series, POLAR 1200 and 1050. The 100% Japanese capacitors and 50°C ambient operations with LLC, DC-DC structure generate an environmentally friendly PSU with high-efficiency performance. The fine-tune HDB fan with zero noise mode will also provide the perfect experience for all users in different conditions.
The Polar series is also certified as PLATINUM efficiency rating from Cybenetics Lab.
EVERY OUTPUT IS WORTH SAVING
Save the Earth with Lesser Energy Loss
- The Polar series will reduce the energy waste below 7%.
- With 80Plus Platinum certified to provide the efficiency level up to 92% at 115Vac.
- Less efficiency loss with streamlined board-to-board wave soldering.
ULTRA-SILENCE AT HIGH OUTPUT
Lower Heat Emission for Steady Temperature
- Zero noise mode at 40% loading silent.
- Automatic thermal control to provide an optimal speed-noise ratio.
Using COUGAR’s 135mm HDB silent fan and large inhalation punched hole, the advanced frame increase the concentration of airflow and its fan curvature has been fine-tuned to reduce vibration.The overall fan combination leads to reaching the low fan noise A+ level, tested by Cybenetics Lab.
REFIND ELECTRONIC SOLUTION
Reduce the E-waste for the Next Generation
- 100% premium Japanese capacitor to prolong the longevity.
- Optimally perform in 50ºC working temperature environments.
- Tight 2% voltage regulation for ultra-stable operation.
- Hybrid Dynamic Bearing (HDB) fan to expand the durability.
- Patented groove design
- Centralized oil pressure
- No oil leakage
- Improved stability
- Less friction and noise
- Extended lifespan
Perfectly Support GeForce RTX™ 30 Series GPU
The POLAR series is designed for high end gamers and complicated media workers which can perfectly supporting RTX 30 series GPU and provide stable performance.
Power | |
| Efficiency | 92% |
| Input current | 15 - 7 A |
| Power protection features | Over current, Overload, Over voltage, Overheating, Short circuit, Under voltage |
| Combined power (+3.3V) | 100 W |
| Combined power (+12V) | 1200 W |
| Combined power (+5V) | 100 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 15 W |
| Max output current (+3.3V) | 20 A |
| Max output current (+12V) | 100 A |
| Max output current (+5V) | 20 A |
| Max output current (+5Vsb) | 3 A |
| Max output current (-12V) | 0.3 A |
| AC input voltage | 100 - 240 V |
| AC input frequency | 47 - 63 Hz |
| Total power | 1200 W |
Performance | |
| Mean time between failures (MTBF) | 100000 h |
| Purpose | PC |
| 80 PLUS certification | 80 PLUS Platinum |
| Silent mode | Yes |
Design | |
| Product colour | Silver |
| Fan diameter | 13.5 cm |
Ports & interfaces | |
| Number of SATA power connectors | 12 |
| Peripheral (Molex) power connectors (4-pin) | 4 |
| CPU power connector (4+4 pin) | Yes |
| PCI Express power connectors (6+2 pin) | 9 |
| Motherboard power connector | 20+4 pin ATX |
| Cabling type | Fully-Modular |
Weight & dimensions | |
| Weight | 2.09 kg |
| Width | 180 mm |
| Depth | 150 mm |
| Height | 86 mm |
Packaging data | |
| Package weight | 3.59 kg |
| Package height | 107 mm |
| Package width | 331 mm |
| Package depth | 229 mm |
Packaging content | |
| Cables included | SATA, CPU, PCIe, PATA |
