Extralink Switch Hypnos 24x RJ45 1000Mb/s, 4x SFP+, L3, managed
1 089.01 €
Monthly payment from 28,94 €
2454331 EX.30660
5905090330660
Shipping 4-5 b.d.
You are interested in this product?
All about the product
Extralink Hypnos - new gigabit managed switch for future-proof deploymentsThe 24-port Gigabit Smart switch with 24 1000BASE-T ports and four 10G SFP slots provides advanced management features with 256 Gbps switching capacity. The Extralink Hypnos is equipped with 1000BASE-T ports that provide higher gigabit speeds up to 1000 Mbps with existing Cat5e or better cabling. This 24-port gigabit switch provides a high-performance switch architecture that greatly simplifies LAN upgrade tasks to meet growing bandwidth demands. The switch's Flow Control feature allows routers and servers to connect directly to the switch for fast and reliable data transfer.
Speeds of 1000 Mbps for applications with varying bandwidths
With data rates of 802.11ac wireless access points reaching as high as 1 Gbps, 100M ports cannot meet the bandwidth demand. Supporting speeds at 1 Gbps, the Extralink Hypnos can deliver data to 802.11ac wireless access points. All RJ45 interfaces on the Extralink Hypnos support 10/100/1000 Mbps auto-negotiation for optimal speed detection along with RJ45 category 6, 5 or 5e cables.
10 Gbps SFP ports for high network performance
Extralink Hypnos provides higher throughput and powerful computing power. It offers a maximum uplink capacity of 40 Gbps through four 10 Gbps SFP ports . In addition, the administrator can flexibly select the appropriate SFP/SFP module depending on the transmission distance or the transmission speed required for efficient network expansion.
Designed with surge protection in mind
Achieving 6 kV surge protection, the Ethernet ports of the Extralink Hypnos switch have immunity to lightning and other electrical surges, offering reliable operation even in harsh environments.
Auto-MDI/MDI-X standard
Extralink Hypnos also supports the auto-MDI/MDI-X standard, which can detect the type of connection to any Ethernet device without the need for special straight or crossover cables.
Network | |
| Networking standards | IEEE 802.3ab, IEEE 802.3u, IEEE 802.3az, IEEE 802.3x, IEEE 802.3z, IEEE 802.3bz, IEEE 802.3i |
| Flow control support | Yes |
| Ethernet LAN data rates | 10, 100, 1000 |
| Static route | Yes |
Management features | |
| Web-based management | Yes |
| Reset button | Yes |
| Quality of Service (QoS) support | Yes |
Security | |
| MAC address table | 32768 entries |
| Access Control List (ACL) | Yes |
Design | |
| LED indicators | Power, Status, System, Link, Data, Uplink |
| Housing material | Metal |
Features | |
| Firmware upgradeable | Yes |
Power | |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power over Ethernet (PoE) | No |
Operational conditions | |
| Operating temperature (T-T) | -20 - 55 °C |
| Storage temperature (T-T) | -40 - 75 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage relative humidity (H-H) | 5 - 95% |
Weight & dimensions | |
| Width | 440 mm |
| Depth | 290 mm |
| Height | 44.5 mm |
| Weight | 3 kg |
Packaging data | |
| Package type | Box |
Other features | |
| Form factor | 1U |
| Rack mounting | Yes |
Packaging content | |
| Cables included | AC |
| Manual | Yes |
