Extralink PoE Inverter 1 Port Input 1x 1000Mb/s RJ45/Jack 10-30V, Output 48V
Extralink PoE Inverter 1 Port Input 1x 1000Mb/s RJ45/Jack 10-30V, Output 48V – 2
Extralink PoE Inverter 1 Port Input 1x 1000Mb/s RJ45/Jack 10-30V, Output 48V – 3
Extralink PoE Inverter 1 Port Input 1x 1000Mb/s RJ45/Jack 10-30V, Output 48V
Extralink PoE Inverter 1 Port Input 1x 1000Mb/s RJ45/Jack 10-30V, Output 48V
Extralink PoE Inverter 1 Port Input 1x 1000Mb/s RJ45/Jack 10-30V, Output 48V
Extralink PoE Inverter 1 Port Input 1x 1000Mb/s RJ45/Jack 10-30V, Output 48V
Extralink PoE Inverter 1 Port Input 1x 1000Mb/s RJ45/Jack 10-30V, Output 48V
Extralink PoE Inverter 1 Port Input 1x 1000Mb/s RJ45/Jack 10-30V, Output 48V
Extralink PoE Inverter 1 Port Input 1x 1000Mb/s RJ45/Jack 10-30V, Output 48V
Extralink PoE Inverter 1 Port Input 1x 1000Mb/s RJ45/Jack 10-30V, Output 48V
Extralink PoE Inverter 1 Port Input 1x 1000Mb/s RJ45/Jack 10-30V, Output 48V

The product's shade and actual color may differ from what is shown in the picture, as the images are for illustrative purposes. The product description is general and may not include all the product's features.

Extralink PoE Inverter 1 Port Input 1x 1000Mb/s RJ45/Jack 10-30V, Output 48V

79.00 €
Monthly payment from 2,93 €
2370522

EX.14671

5903148914671

Shipping 4-5 b.d.

You are interested in this product?
(Read terms of service)

All about the product

Extralink poe injector
The Poe injector allows you to bring power to your 10/100/1000mbps network over CAT5e, CAT6 or CAT6A Ethernet cable. The power source can be any power supply from 10V to 30V and the output voltage of the injector is 48V. The poe adapter can be powered from the DC jack 5.5/2.1 mm connector - or from the RJ45 plug pins - 4.5 (plus) and 7.8 - (minus). Thanks to the poe injector, a battery (12V or 24V) or passive PoE (10V-30V) can be used to power the 48V device.
When connecting power to the DC jack 2.1mm input - the power will be isolated from the male RJ-45 connector - so it can be connected to a switch or router. The 48V output voltage is delivered to pins 3.6 (plus) and 1.2 - (minus) of the RJ-45 female jack to power any 802.3af device. This converts both the voltage that the receiving device is powered by and the pins on which the power over ethernet operates.
Network
Networking standards IEEE 802.3at, IEEE 802.1af
Ethernet LAN data rates 10, 100, 1000
Auto MDI/MDI-X Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports 1
DC-in jack Yes
Management features
Web-based management No
Design
LED indicators Link
Product colour Black
Wall mountable No
Features
Firmware upgradeable No
Plug and Play Yes
Power
Power over Ethernet (PoE) Yes
Power over Ethernet (PoE) voltage 48 V
Packaging data
Package type Box
Number of products included 1 pc(s)
Other features
Compliance industry standards CE. RoHs
Rack mounting No
Packaging content
AC adapter included No
Manual No
Quick installation guide No
