Neomounts DS75S-950WH2 Monitor arm 17-32" - gas spring - Topfix - 180°-stop
419,00 €
Monthly payment from 11.69 €
2295812 DS75S-950WH2
8717371441586, 0871737144158
Shipping 3-7 b.d.
You are interested in this product?
The DS75S-950WH2 features the nifty 180° stop mechanism, that allows you to safely adjust the mount even when it's placed close to a wall or separation panel without making contact with the wall. The smart cable management system ensures orderly routing of the cables.
The black VESA plates and crossbar of the NEXT One integrate stylishly with the black back of your screens. The DS75S-950WH2 is suitable for screens that meet VESA hole pattern 75x75 or 100x100 mm. For non-standard hole patterns, Neomounts has various optional VESA adapter plates available. The monitor arm is equipped with a Quick-release VESA system and comes with both a topfix clamp and grommet for quick and easy installation.
The packaging of the DS75S-950WH2 desk mount is 100% plastic free and entirely made from cardboard and paper. The NEXT One products have an extended warranty period of 10-years.
Features | |
| Panel mounting interface | 75 x 75, 100 x 100 |
| Minimum screen size | 43.2 cm (17") |
| Maximum screen size | 81.3 cm (32") |
| Number of displays supported | 2 |
| Minimum VESA mount | 75 x 75 mm |
| Maximum VESA mount | 100 x 100 mm |
| Mounting type | Desk |
| Height adjustment | Yes |
| Tilt angle range | -60 - 60° |
| Swivel angle range | -90 - 90° |
| Height adjustment range | 191 - 527 mm |
| Cable management | Yes |
| Angle of rotation | 360° |
| Adjustable depth | Yes |
| Rotating | Yes |
| Tilt adjustment | Yes |
| Swivelling | Yes |
| Product colour | White |
| Housing material | Aluminium |
| Width adjustment range | 0 - 1074 mm |
| Depth adjustment range | 173 - 710 mm |
Mounting | |
| Maximum weight capacity (per display) | 8 kg |
Ergonomics | |
| Distance to the wall (max) | 74.1 cm |
| Distance to the wall (min) | 20.4 cm |
| Height adjustment type | Gas spring |
Packaging data | |
| Package weight | 7.1 kg |
| Package depth | 120 mm |
| Package height | 887 mm |
| Package width | 222 mm |
Weight & dimensions | |
| Weight | 5.76 kg |
| Width | 833 mm |
| Depth | 739 mm |
| Height | 1085 mm |
| Minimum weight | 1 kg |
Technical details | |
| Country of origin | China |
| Package net weight | 7.1 kg |
| Easy to install | Yes |
| Desk thickness (min) | 1 cm |
| Desk thickness (max) | 5.5 cm |
| Warranty period | 10 year(s) |
Logistics data | |
| Master (outer) case width | 240 mm |
| Master (outer) case length | 260 mm |
| Master (outer) case height | 905 mm |
| Master (outer) case gross weight | 15 kg |
| Products per master (outer) case | 2 pc(s) |
| Master (outer) case net weight | 11.6 kg |
| Harmonized System (HS) code | 7326909890 |
| Products per pallet (EU) | 36 pc(s) |
Other features | |
| Mounting | Clamp/Grommet |
