Synology RackStation RS3618xs NAS Rack (2U) Intel® Xeon® D D-1521 8 GB DDR4 0 TB DiskStation Manager Black
3 565.50 €
Monthly payment from 92,71 €
2067290 RS3618XS
4711174723058, 0846504003051
Shipping 12-13 b.d.
You are interested in this product?
All about the product
Central Management System
Conveniently manage your fleet of Synology NAS from a centralized console.
Snapshot Replication
Schedulable and instantaneous data protection for shared folders and iSCSI LUNs for disaster prevention.
Virtual Machine Manager
Run various operating systems in isolated sandboxes. Seamlessly clone, store, and migrate virtual machines.
Features
| Operating system installed | DiskStation Manager |
| Wi-Fi | No |
| Product colour | Black |
| USB 2.0 ports quantity | 0 |
| Processor frequency | 2.4 GHz |
| Processor family | Intel® Xeon® D |
| Processor model | D-1521 |
| Processor cores | 4 |
| USB port | Yes |
| Weight | 14.5 kg |
| Width | 430.5 mm |
| Depth | 692 mm |
| Height | 88 mm |
| Cables included | AC |
| Type | NAS |
| Internal memory | 8 GB |
| Internal memory type | DDR4 |
| Memory clock speed | 2133 MHz |
| Cooling type | Active |
| Windows operating systems supported | Windows 7; Windows 10 |
| Mac operating systems supported | Mac OS X 10.11 El Capitan; Mac OS X 10.12 Sierra |
| Certification | EAC, VCCI, CCC, RCM, FCC, CE, BSMI |
| Operating temperature (T-T) | 5 - 35 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 4 |
| Ethernet LAN data rates | 10; 100; 1000 |
| LED indicators | Power; HDD |
| AC input voltage | 100 - 240 V |
| Power consumption (typical) | 142.76 W |
| Mac compatibility | Yes |
| Quick installation guide | Yes |
| On/off switch | Yes |
| AC input frequency | 50 - 60 Hz |
| Fan diameter | 8 cm |
| Number of fans | 4 fan(s) |
| Noise level | 50.2 dB |
| Supported storage drive interfaces | Serial ATA; Serial ATA II; Serial ATA III |
| Number of storage drives supported | 12 |
| Security algorithms | SSH; SSL/TLS; HTTPS |
| Operating altitude | 0 - 5000 m |
| Supported network protocols | CIFS, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, VPN (PPTP, OpenVPN) |
| Thermal Design Power (TDP) | 45 W |
| Browser supported | Chrome, Firefox, Internet Explorer 10, Safari |
| Processor manufacturer | Intel |
| Processor boost frequency | 2.7 GHz |
| Processor cache | 6 MB |
| Memory slots | 4 |
| Chassis type | Rack (2U) |
| Intel 64 | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Embedded options available | No |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Idle States | Yes |
| Intel Trusted Execution Technology | Yes |
| Execute Disable Bit | Yes |
| CPU configuration (max) | 1 |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Harmonized System (HS) code | 84714100 |
| Processor socket | BGA 1667 |
| Processor threads | 8 |
| Processor lithography | 14 nm |
| Processor operating modes | 64-bit |
| Processor codename | Broadwell |
| PCI Express slots version | 3.0; 2.0 |
| Maximum number of PCI Express lanes | 32 |
| PCI Express configurations | 1x16; 1x4; 1x8 |
| Maximum internal memory supported by processor | 128 GB |
| Memory types supported by processor | DDR4-SDRAM; DDR3-SDRAM |
| Thermal Monitoring Technologies | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Secure Key | Yes |
| Intel® OS Guard | Yes |
| Processor package size | 37.5 x 37.5 mm |
| Scalability | 1S |
| Processor ARK ID | 91202 |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| ECC supported by processor | Yes |
| Storage drive sizes supported | 2.5; 3.5 |
| Supported storage drive types | HDD & SSD |
| PCI Express x8 (Gen 3.x) slots | 2 |
| Reset button | Yes |
| Intel TSX-NI | Yes |
| Web-based management | Yes |
| Link aggregation | Yes |
| Access Control List (ACL) | Yes |
| Number of storage drives installed | 0 |
| Server operating systems supported | Windows Server 2012; Windows Server 2012 R2 |
| Number of power supply units | 1 |
| RAID levels | 0; 1; 5; 6; 10; JBOD; F1 |
| S.M.A.R.T. support | Yes |
| Fiber ports quantity | 0 |
| Wake-on-LAN ready | Yes |
| Number of users | 16000 user(s) |
| Supported file systems | NTFS; ext3; ext4; HFS+; BTRFS; Fat |
| Processor series | Intel Xeon D-1500 |
| Intel Enhanced Halt State | Yes |
| Processor code | SR2DF |
| Intel Secure Key Technology version | 1.00 |
| Intel TSX-NI version | 1.00 |
| Conflict-Free processor | Yes |
| iSCSI support | Yes |
| Stepping | V2 |
| RAID support | Yes |
| Memory channels supported by processor | Dual |
| UART | Yes |
| Storage drives installed | No |
| Total installed storage capacity | 0 TB |
| Installed storage drive type | No |
| Storage drive capacity | 0 GB |
| Hot-swap drive bays | Yes |
| Device class | Small & Medium Business |
| Backup function | Yes |
| Backup features | Cloud; iSCSI LUN |
| Power supply location | Built-in |
| Maximum RAM supported | 64 GB |
| Multilingual support | Yes |
| System log | Yes |
| Hot spare | Yes |
| Share folder | CIFS/AFP/FTP |
| Power supply unit (PSU) capacity | 500 W |
| Power consumption (HDD standby) | 55.05 W |
| Maximum supported storage capacity | 144 TB |
| Compliance certificates | RoHS |
