Zyxel RGS100-5P Unmanaged L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
433.74 €
Monthly payment from 12,07 €
2040933 RGS100-5P-ZZ0101F
4718937592036, 0760559123970
Shipping 14-15 b.d.
You are interested in this product?
All about the product
5-port GbE Unmanaged PoE SwitchAlong with the complete commercial product portfolio that offers customers with total network solutions, Zyxel introduces the new RGS100-5P PoE switch with ruggedized design concepts to meet stringent outdoor or harsh network deployment scenarios. The wide operating temperature range ensures reliable performance in adverse environments and expands RGS100-5P’s network availability in a wide variety of field applications.
Benefits
Rugged and reliable design for harsh environments
Designed with fanless and IP30 standard metal mechanism, the Zyxel RGS100-5P is able to to deliver excellent thermal controls and withstand dusty environments and can be installed on either a DIN rail or wall mount for efficient use of cabinet space. In addition, wide-ranging operating temperature tolerance allows RGS100-5P to be deployed across a spectrum of harsh environments. Equipped with dual DC power inputs, the RGS100-5P is capable of highavailability operation and resilience under the most demanding conditions. When switching is applied normally in outdoor settings, ESD (electrostatic discharge) and DC surge protection prevent the loss of business revenue and productivity due to damage or fatigue caused by power disturbances.
Trouble-free installation and easy extendibility
This rugged unmanaged PoE switch comes with four (4) 10/100/1000 Base-T copper PoE ports and one (1) 100/1000-Base-X SFP fiber interface. The switch also supports the 802.3at PoE plus standard, with each PoE port providing up to 30W of power to efficiently accommodate the most power-hungry devices. The fiber uplink can extend the network to long-distance nodes up to 40 km (43,744 yards) away for added flexibility.
Plug-and-Play deployments
The Zyxel RGS100-5P is able to negotiate the optimal data speed and activate duplex mode automatically with N-Way feature. It can also detect the type of connection to any Ethernet device with support for auto-MDI/MDI-X. Broadcast storm protection can easily be activated via DIP switch. Plug-and-play makes deploying the RGS100-5P hassle-free for any application or scenario.
Network | |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x, IEEE 802.1p, IEEE 802.3z |
| Flow control support | Yes |
| Auto MDI/MDI-X | Yes |
| Full duplex | Yes |
| Multicast support | Yes |
| Jumbo frames support | Yes |
| Jumbo frames | 9000 |
Ports & interfaces | |
| Fiber optic connector | SFP |
Security | |
| MAC address table | 2000 entries |
Design | |
| Product colour | Black |
| Housing material | Metal |
| Wall mountable | Yes |
| International Protection (IP) code | IP30 |
Features | |
| Plug and Play | Yes |
| Heat dissipation | 42625 BTU/h |
| Mean time between failures (MTBF) | 568430 h |
Power | |
| Power over Ethernet (PoE) | Yes |
Operational conditions | |
| Operating temperature (T-T) | -40 - 75 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage relative humidity (H-H) | 5 - 90% |
Weight & dimensions | |
| Width | 29.1 mm |
| Depth | 107.3 mm |
| Height | 139 mm |
| Weight | 500 g |
Packaging data | |
| Package width | 70 mm |
| Package depth | 177.8 mm |
| Package height | 205 mm |
| Package weight | 700 g |
Other features | |
| Input voltage | 12 - 58 V |
| Rack mounting | Yes |
Logistics data | |
| Harmonized System (HS) code | 85176990 |
