Chieftec Polaris PRO 1300W power supply unit 20+4 pin ATX ATX Black
299,00 €
269.00 €
Monthly payment from 7,83 €
2024969 PPX-1300FC-A3
0753263078162
Shipping 12-13 b.d.
You are interested in this product?
All about the product
The CHIEFTEC Polaris Pro Series features advanced thermal control with the Zero RPM mode, enabling the optimal balance between silence at low power consumption and ideal cooling, with 80 PLUS® PLATINUM certified efficiency. Polaris Pro Series is designed for Intel’s state-of-the-art ATX 3.0 standard with native PCIe GEN5 connector. The Polaris Pro Series is built with 100% high-end Japanese capacitors to achieve unprecedented tight voltage regulation and lower ripple and noise to maximize your system performance and excellent durability. Fully modular cable management ensures a clean and convenient build inside any system.Power | |
| Input current | 15-8 A |
| Power protection features | Over current, Overload, Over voltage, Short circuit, Under voltage |
| Power factor | 0.9 |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 120 W |
| Combined power (+5V) | 120 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 15 W |
| Max output current (+3.3V) | 24 A |
| Max output current (+5V) | 24 A |
| Max output current (+5Vsb) | 3 A |
| Max output current (-12V) | 0.3 A |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Max output current (+12V1) | 108.3 A |
| Total power | 1300 W |
Performance | |
| ATX version | 3.0 |
| Purpose | PC |
| 80 PLUS certification | 80 PLUS Platinum |
| Bearing technology | FDB |
| Power supply unit (PSU) form factor | ATX |
Design | |
| Product colour | Black |
| Fan diameter | 13.5 cm |
| Cooling type | Active |
Ports & interfaces | |
| Floppy drive power connector | 1 |
| Number of SATA power connectors | 12 |
| EPS power connector (8-pin) | Yes |
| Peripheral (Molex) power connectors (4-pin) | 4 |
| PCI Express power connectors (6+2 pin) | 6 |
| Motherboard power connector | 20+4 pin ATX |
| Cabling type | Fully-Modular |
| Floppy disk drive connector | Yes |
| Motherboard power cable length | 60 cm |
| SATA power cable length | 550, 100 |
| Peripheral (Molex) power cable length | 150, 500 |
| PCI Express power connectors (16-pin) | 1 |
Weight & dimensions | |
| Weight | 3.13 kg |
| Width | 150 mm |
| Depth | 160 mm |
| Height | 86 mm |
Packaging data | |
| Package weight | 3.49 kg |
| Package type | Box |
Logistics data | |
| Warranty period | 5 year(s) |
