Western Digital Ultrastar DC HC560 internal hard drive 20 TB 7200 RPM 512 MB 3.5" Serial ATA
1 170,49 €
Monthly payment from 31.04 €
1904312 0F38785
8032976149034, 0829686008410, 1296860084178, 3807000011381, 5054444493435, 5715063043011, 8592978389734
2026-07-31
You are interested in this product?
An innovative storage architecture to help our customers meet their need for exponential data growth.
Reimagining the HDD for Exponential Data Growth
Hyperscale cloud, CSPs, enterprises, smart video surveillance partners, NAS suppliers and more need storage solutions to meet the exponential growth in data creation. When it comes to cost-effective storage of data at scale, hard disk drives (HDDs) continue to play a central role. HDDs deliver the capacity, performance and reliability needed to store vast amounts of data today and well into the future. Investments in HDD technology remain critical to supporting worldwide data growth.
Western Digital has developed flash-enhanced drives with OptiNAND™ technology by vertically integrating our leading NAND flash with our world-class HDDs. Western Digital HDDs have been leaders in areal density with industry first technologies of energy-assisted magnetic recording technology (EAMR), triple-stage actuator (TSA), HelioSeal®, and now OptiNAND technology. Higher areal density means higher capacities to meet storage challenges.
20TB1 HDDs with OptiNAND Technology
OptiNAND integrates an iNAND® Universal Flash Storage (UFS) Embedded Flash Drive (EFD) with traditional spinning disk media, and incorporates innovative changes to the firmware algorithm and system-on-a-chip (SoC). OptiNAND is not a hybrid technology. The drive works smarter, with enhanced firmware algorithms taking advantage of expanded metadata that has been offloaded to the iNAND, enabling more tracks per inch (TPI) with resulting increased areal density.
The Ultrastar DC HC560, with the first implementation of OptiNAND technology’s capacity-enabling features, delivers an unbeaten 20TB capacity in a nine-disk platform (2.2TB/platter) with CMR recording format
Features | |
| HDD capacity | 20 TB |
| Average latency | 4.16 ms |
| HDD speed | 7200 RPM |
| Mean time between failures (MTBF) | 2.5 h |
| HDD size | 3.5" |
| Interface | Serial ATA |
| HDD interface transfer rate | 6 Gbit/s |
| HDD sustained transfer rate | 257 MiB/s |
| Component for | Server/workstation |
| Workload rate limit | 550 TB/year |
| Storage drive buffer size | 512 MB |
| Type | HDD |
| 24/7 operation | Yes |
Power | |
| Operating voltage | 5 / 12 V |
Operational conditions | |
| Operating temperature (T-T) | 5 - 60 °C |
| Operating shock | 50 G |
| Storage temperature (T-T) | -40 - 70 °C |
| Non-operating shock | 250 G |
| Operating vibration | 0.7 G |
| Non-operating vibration | 1.04 G |
Weight & dimensions | |
| Weight | 690 g |
| Height | 147 mm |
| Width | 101.6 mm |
| Depth | 26.2 mm |
Other features | |
| Windows operating systems supported | Yes |
| Linux operating systems supported | Yes |
Logistics data | |
| Harmonized System (HS) code | 84717050 |
