Thermaltake SFX-750AH8FKG power supply unit 750 W 24-pin ATX ATX Black
165,83 €
164.81 €
Monthly payment from 5,14 €
1761779 PS-STP-0750FNFAGE-1
4713227534994
Shipping 14-15 b.d.
You are interested in this product?
All about the product
Thermaltake SFX-750AH8FKG. Total power: 750 W, AC input voltage: 100 - 240 V, AC input frequency: 50 - 60 Hz. Motherboard power connector: 24-pin ATX, Motherboard power cable length: 30 cm, SATA power cable length: 300 mm. Purpose: PC/Server, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Cooling type: Active, Fan diameter: 9.2 cm. Cables included: AC, CPU, PCIe, Peripheral (Molex), SATAPower | |
| Hold time | 17 ms |
| Efficiency | 100% |
| Input current | 10 A |
| Power protection features | Over current, Overload, Over voltage, Overheating, Short circuit, Under voltage |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 100 W |
| Combined power (+12V) | 750 W |
| Combined power (+5V) | 100 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 15 W |
| Max output current (+3.3V) | 20 A |
| Max output current (+12V) | 62.5 A |
| Max output current (+5V) | 20 A |
| Max output current (+5Vsb) | 3 A |
| Max output current (-12V) | 0.3 A |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Total power | 750 W |
Performance | |
| Mean time between failures (MTBF) | 100000 h |
| ATX version | 3.0 |
| Purpose | PC/Server |
| 80 PLUS certification | 80 PLUS Gold |
| Bearing technology | FDB |
| Power supply unit (PSU) form factor | ATX |
| Supported motherboard form factors | Mini-ITX, ATX, micro ATX, Mini-ATX |
Design | |
| Product colour | Black |
| Number of fans | 1 fan(s) |
| Fan diameter | 9.2 cm |
| Fan location | Top |
| Cooling type | Active |
| On/off switch | Yes |
Ports & interfaces | |
| ATX Power connector (24-pin) | Yes |
| Number of SATA power connectors | 8 |
| Peripheral (Molex) power connectors (4-pin) | 4 |
| CPU power connector (4+4 pin) | Yes |
| PCI Express power connectors (6+2 pin) | 2 |
| Motherboard power connector | 24-pin ATX |
| Cabling type | Fully-Modular |
| PCI Express connector | Yes |
| Floppy disk drive connector | Yes |
| Motherboard power cable length | 30 cm |
| SATA power cable length | 300 mm |
| Peripheral (Molex) power cable length | 300 mm |
| PCI Express power cable length | 4 m |
| CPU power cable length | 40 cm |
| Floppy disk drive cable length | 15 cm |
| PCI Express power connectors (16-pin) | 1 |
Operational conditions | |
| Operating relative humidity (H-H) | 5 - 85% |
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 95% |
Weight & dimensions | |
| Weight | 1 kg |
| Width | 125 mm |
| Depth | 100 mm |
| Height | 63.5 mm |
Technical details | |
| Sustainability compliance | Yes |
Packaging content | |
| Cables included | AC, SATA, CPU, PCIe, Peripheral (Molex) |
Certificates | |
| Compliance certificates | CE, Federal Communications Commission (FCC), Low Voltage Directive (LVD), UKCA, BSMI, CB, cTUVus, CCC, CES |
