The product's shade and actual color may differ from what is shown in the picture, as the images are for illustrative purposes. The product description is general and may not include all the product's features.
Neomounts DS70-750BL1 Monitor arm 17-27" - gas spring
116,00 €
Monthly payment from 3.89 €
1132051 DS70-750BL1
8717371449193
Shipping 2-3 b.d.
You are interested in this product?
The DS70-750BL1 is suitable for screens that meet VESA hole pattern 75x75 or 100x100mm. Unused hole patterns can be covered using one of Neomounts VESA adapter plates. The DS70-750BL1 is equipped with an Easy-release VESA system for easy installation and comes with both desk clamp and grommet.
Features | |
| Maximum weight capacity | 7 kg |
| Panel mounting interface | 75 x 75 mm |
| Minimum screen size | 43.2 cm (17") |
| Maximum screen size | 68.6 cm (27") |
| Number of displays supported | 1 |
| Minimum VESA mount | 75 x 75 mm |
| Maximum VESA mount | 100 x 100 mm |
| Mounting type | Desk |
| Height adjustment | Yes |
| Tilt angle range | -45 - 45° |
| Swivel angle range | -90 - 90° |
| Height adjustment range | 73 - 481 mm |
| Cable management | Yes |
| Angle of rotation | 360° |
| Adjustable depth | Yes |
| Rotating | Yes |
| Tilt adjustment | Yes |
| Swivelling | Yes |
| Product colour | Black |
| Housing material | Steel |
| Width adjustment range | 0 - 378 mm |
| Depth adjustment range | 0 - 440 mm |
Mounting | |
| Maximum weight capacity (per display) | 7 kg |
Ergonomics | |
| Pivot angle | -180 - 180° |
| Height adjustment type | Gas spring |
Packaging data | |
| Package weight | 3.1 kg |
| Package depth | 116 mm |
| Package height | 365 mm |
| Package width | 240 mm |
| Quantity per pack | 1 pc(s) |
Weight & dimensions | |
| Weight | 2.54 kg |
| Width | 117 mm |
| Depth | 440 mm |
| Height | 679 mm |
| Minimum weight | 2 kg |
Technical details | |
| Country of origin | China |
| Package net weight | 3.1 kg |
| Desk thickness (min) | 1 cm |
| Desk thickness (max) | 8.5 cm |
| Orientation | Landscape/Portrait |
Logistics data | |
| Master (outer) case width | 495 mm |
| Master (outer) case length | 380 mm |
| Master (outer) case height | 365 mm |
| Master (outer) case gross weight | 19.5 kg |
| Products per master (outer) case | 6 pc(s) |
| Master (outer) case net weight | 15.2 kg |
| Harmonized System (HS) code | 7326909890 |
| Products per pallet (EU) | 96 pc(s) |
Other features | |
| Mounting | Clamp/Grommet |
