The product's shade and actual color may differ from what is shown in the picture, as the images are for illustrative purposes. The product description is general and may not include all the product's features.

Seasonic Prime GX-650 power supply unit 650 W 20+4 pin ATX ATX Black

127,99 €
124.99 €
Monthly payment from 4,12 €
732166

PRIME-GX-650

4711173874256

Shipping 13-14 b.d.

You are interested in this product?
(Read terms of service)

All about the product

80 PLUS® GOLD

The PRIME Gold Series achieves 80 PLUS® Gold certification with its 90 % efficiency at 50 % system load.

Power
Input current 9 - 4.5 A
Power protection features Over current, Overload, Over voltage, Overheating, Short circuit, Under voltage
Combined power (+3.3V) 100 W
Combined power (+12V) 648 W
Combined power (+5V) 100 W
Combined power (-12V) 3.6 W
Combined power (+5Vsb) 15 W
Max output current (+3.3V) 20 A
Max output current (+12V) 54 A
Max output current (+5V) 20 A
Max output current (+5Vsb) 3 A
Max output current (-12V) 0.3 A
AC input voltage 100 - 240 V
AC input frequency 50 - 60 Hz
Total power 650 W
Performance
Mean time between failures (MTBF) 150000 h
Purpose PC
80 PLUS certification 80 PLUS Gold
Bearing technology FDB
Power supply unit (PSU) form factor ATX
Design
Product colour Black
Number of fans 1 fan(s)
Fan diameter 13.5 cm
Fan location Top
Cooling type Active
On/off switch Yes
Ports & interfaces
Floppy drive power connector 1
Number of SATA power connectors 10
Peripheral (Molex) power connectors (4-pin) 3
ATX power connector (20+4 pin) Yes
CPU power connector (4+4 pin) Yes
PCI Express power connectors (6+2 pin) 4
Motherboard power connector 20+4 pin ATX
Cabling type Fully-Modular
PCI Express connector Yes
Floppy disk drive connector Yes
Motherboard power cable length 61 cm
SATA power cable length 450, 470, 570, 700, 760
Peripheral (Molex) power cable length 470, 690
PCI Express power cable length 75 cm
CPU power cable length 65 cm
Floppy disk drive cable length 10.1 cm
Operational conditions
Operating temperature (T-T) 0 - 50 °C
Weight & dimensions
Width 150 mm
Depth 140 mm
Height 86 mm
Technical details
Sustainability certificates ENERGY STAR
Packaging data
Manual Yes
Package type Box
Other features
Screws included Yes
Number of screws 4
Logistics data
Harmonized System (HS) code 84733020
Packaging content
Cables included AC, SATA, PCIe
Certificates
Certification cTUVus, TUV, CB, CCC, BSMI, EAC, CE, WEEE, ErP Lot 6, REACH
Compliance certificates RoHS
