D-Link 15.4w Gigabit PoE Injector
39.73 €
Monthly payment from 1,92 €
644737 DPE-101GI
0790069341335, 0012951525235, 0041114195664, 0132018352045, 0163120870516, 0172302833270, 0739923333871, 0790069368011, 0790069378201, 0790069403026, 5052916775409, 7900693413350, 7900693680110
Shipping 14-15 b.d.
You are interested in this product?
All about the product
The DPE-101GI Gigabit PoE Injector is designed to supply a power and data connection to PoE devices such as an IP Camera or Wireless Access Point. The IEEE 802.3af compliant DPE-101GI gives you the ability to mount your PoE device virtually anywhere in a building, such as on ceilings or near entryways, by eliminating the need for a nearby power outlet and attached power supply. D-Link’s DPE-101GI combines electrical power with a Gigabit network connection and produces a Gigabit Power over Ethernet (PoE) signal, allowing a single Ethernet cable to carry both data and power to a device.Cost Efficient Flexibility Deploying the DPE-101GI saves both installation costs and equipment costs, allowing a single RJ-45 Ethernet cable to carry both power and data to each device. This reduces cables, eliminates the need for dedicated electrical outlets on the wall, ceiling, or other unreachable place, and most of all, reduces installation time. The Power over Ethernet solution frees IP surveillance cameras and wireless AP deployments from the restrictions of power outlet locations.
High Speed Connectivity The DPE-101GI Gigabit PoE Injector is designed to be deployed in situations where high bandwidth is demanded. Examples where the DPE-101GI is ideal include powering network devices such as wall mounted PTZ (Pan, Tilt & Zoom) network cameras, ceiling mounted PTZ dome network cameras, video and voice over IP (VoIP) telephones, and wireless LAN access points.
Network | |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3af |
| Ethernet LAN data rates | 10, 100, 1000 |
| Cabling technology | 10/100/1000 |
Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 2 |
| DC-in jack | Yes |
Design | |
| LED indicators | Yes |
| Product colour | White |
| Wall mountable | Yes |
Features | |
| Plug and Play | Yes |
Power | |
| Output current | 0.4 A |
| Power over Ethernet (PoE) | Yes |
Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
Weight & dimensions | |
| Width | 62.2 mm |
| Depth | 109.8 mm |
| Height | 24.5 mm |
| Weight | 65 g |
Packaging data | |
| Package width | 153 mm |
| Package depth | 213 mm |
| Package height | 68 mm |
| Package weight | 420 g |
| Number of products included | 1 pc(s) |
Certificates | |
| Certification | CE, FCC, C-Tick, VCCI, IC |
Logistics data | |
| Shipping (inner) case height | 36 cm |
| Shipping (inner) case width | 23.3 cm |
| Shipping (inner) case length | 32.6 cm |
| Shipping (inner) case net weight | 4.26 kg |
| Products per shipping (inner) case | 10 pc(s) |
| Pallet gross weight (air) | 316.4 kg |
| Master (outer) cases per pallet (air) | 60 pc(s) |
| Products per pallet (air) | 600 pc(s) |
| Pallet gross length | 120 cm |
| Pallet gross width | 110 cm |
| Pallet height (air) | 194 cm |
| Pallet gross weight (sea) | 316.4 kg |
| Master (outer) cases per pallet (sea) | 60 pc(s) |
| Products per pallet (sea) | 600 pc(s) |
| Pallet height (sea) | 194 cm |
| Shipping (inner) case gross weight | 4.94 kg |
| Harmonized System (HS) code | 85044095 |
