MEAN WELL HLG-320H-24B power adapter/inverter Indoor 320 W Silver
169.10 €
Monthly payment from 5,25 €
3619961 HLG-320H-24B
4021087009713
Shipping 5-8 b.d.
You are interested in this product?
All about the product
Mean Well HLG-320H-24B specifications: AC-DC Single output LED driver Mix mode (CV+CC); Output 24Vdc at 13.34A; IP67; cable output; Dimming with 1-10V PWM resistanceFeatures
| Product colour | Silver |
| Weight | 2.03 kg |
| Width | 90 mm |
| Depth | 256 mm |
| Height | 43 mm |
| Purpose | Lighting |
| Operating temperature (T-T) | -40 - 70 °C |
| Storage temperature (T-T) | -40 - 80 °C |
| Operating relative humidity (H-H) | 20 - 95% |
| Output voltage | 24 V |
| Output current | 13.34 A |
| Input voltage | 90-305 V |
| Efficiency | 94% |
| Power protection features | Over current; Over voltage; Short circuit |
| Storage relative humidity (H-H) | 10 - 95% |
| Power supply type | Indoor |
| Output power | 320 W |
| Input frequency | 47/63 Hz |
| Adjustable output voltage | Yes |
| Power current type | AC-to-DC |
| Compliance certificates | RoHS |
