MEAN WELL NDR-75-48 power supply unit 76.8 W Blue, Metallic
36,38 €
35.43 €
3045031 NDR-75-48
6282234036091
Shipping 8-12 b.d.
You are interested in this product?
All about the product
- Universal AC input / Full range- Protections: Short circuit / Overload / Over voltage/ Over temperature
- Cooling by free air convection
- Can be installed on DIN rail TS-35/7.5 or 15
- UL 508 (industrial control equipment) approved
- EN61000-6-2(EN50082-2) industrial immunity level
- 100% full load burn-in test
- 3 years warranty
Features
| Product colour | Metallic; Blue |
| Width | 32 mm |
| Depth | 102 mm |
| Height | 125.2 mm |
| Cooling type | Passive |
| Package weight | 510 g |
| Total power | 76.8 W |
| Operating temperature (T-T) | -20 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 20 - 95% |
| AC input voltage | 90 - 264 V |
| Input current | 0.9 - 1.45 A |
| AC input frequency | 47 - 63 Hz |
| Efficiency | 89% |
| Power protection features | Overload; Over voltage; Overheating; Short circuit |
| Mean time between failures (MTBF) | 486200 h |
| Storage relative humidity (H-H) | 10 - 95% |
| Safety | Ul508, TUV EN60950-1 approved;(meet EN60204-1) |
| Hold time | 60 ms |
| Rise time | 60 ms |
