Epson EB-770Fi
Epson EB-770Fi – 2
Epson EB-770Fi – 3
Epson EB-770Fi – 4
Epson EB-770Fi – 5
Epson EB-770Fi
Epson EB-770Fi
Epson EB-770Fi
Epson EB-770Fi
Epson EB-770Fi
Epson EB-770Fi
Epson EB-770Fi
Epson EB-770Fi
Epson EB-770Fi
Epson EB-770Fi
Epson EB-770Fi
Epson EB-770Fi
Epson EB-770Fi
Epson EB-770Fi
Epson EB-770Fi

The product's shade and actual color may differ from what is shown in the picture, as the images are for illustrative purposes. The product description is general and may not include all the product's features.

Epson EB-770Fi

3 611.57 €
Monthly payment from 93,90 €
2096445

V11HA78080

8715946715230

Shipping 14-15 b.d.

You are interested in this product?
(Read terms of service)

All about the product

Legal Statement

Complies with The UK Product Security and Telecommunications Infrastructure (Product Security) requirements. Epson will provide security updates for 7 years from purchase

Projector
Projection technology 3LCD
Projector brightness 4100 ANSI lumens
Contrast ratio (typical) 2500000:1
Vertical scan range 192 - 240 Hz
Heat dissipation 895 BTU/h
Keystone correction, horizontal ±3°
Keystone correction, vertical ±3°
Screen size compatibility 1524 - 2540 mm (60 - 100")
Projector brightness (economic mode) 2800 ANSI lumens
Contrast ratio (dynamic) 5000000:1
Native aspect ratio 16:9
Projector native resolution 1080p (1920x1080)
Number of colours 1.07 billion colours
Zoom capability Yes
Focal length range 3.7 mm
Country of origin Philippines
Light source
Light source type Laser
Service life of light source 20000 h
Service life of light source (economic mode) 30000 h
Lens system
Throw ratio 0.25 - 0.35:1
Zoom ratio 1.35:1
Focus Manual
F-number (relative aperture) 1.6
Fixed focal length 3.7 mm
Video
Full HD Yes
Analog signal format system Not supported
3D No
Video processing 10 bit
Video colour modes Cinema, Dynamic, Blackboard, Presentation, sRGB, DICOM simulation mode
Technical details
Serial interface type RS-232C
Other features 21:9 aspect ratio support, A/V mute, Arc Correction, Auto Power On, Auto source search, Built-in speaker, CEC compatible, Digital zoom, Direct Power on/off, Document Camera Compatible, Dual Pen Support, Easy OSD pre-setting, Email notification, Finger-touch support, Home Screen, Horizontal and vertical keystone correction, Image Shift, Instant on/off, Interactive, Interactive Home Screen, Interactive OSD menu, Mail notification function, Microphone input, Network administration, Network projection, OSD copy function, PC Interactive, PC free annotation, Projection App for Chromebook, Quick Corner, Schedule Function, Screen Mirroring, Screen share, Split-Screen-Function, Ultra-wide display (16:6), Web Control, Web Remote, Whiteboard sharing function, Wireless LAN capable, iProjection App, iProjecton set-up by scanning a code
Power consumption 197 Watt (Normal On-Mode), 141 Watt (Eco On-Mode), 263 Watt (Normal Peak-mode), 199 Watt (Eco Peak-Mode), 0.5 Watt (Energy saving standby)
Ports & interfaces
Composite video in 0
Component video (YPbPr/YCbCr) in 0
USB 2.0 ports quantity 4
DVI port No
HDMI ports quantity 3
Microphone in Yes
VGA (D-Sub) ports quantity 2
USB 2.0 Type-B ports quantity 2
USB 2.0 Type-A ports quantity 2
Interface USB 2.0-A (2x), USB 2.0 Type B (Service Only) (2x), RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), Wireless LAN IEEE 802.11a/b/g/n/ac, Wi-Fi Direct, VGA in (2x), VGA out, HDMI in (3x), Composite in, Miracast, Jack plug out, Jack plug in (3x), Microphone input, Sync. in, Sync. out, Multi-Touch interface (optional)
Storage
Card reader integrated No
Features
Noise level 37 dB
Noise level (economic mode) 27 dB
Password protection Yes
Interactive input supported Interactive pen/Touch
Interactive Yes
Multimedia
RMS rated power 16 W
Built-in speaker(s) Yes
Design
Cable lock slot Yes
Cable lock slot type Kensington
Product type Ultra short throw projector
Market positioning Presentation
Placement Desktop, Wall, Ceiling
Colour
Product colour White
Operational conditions
Power consumption (typical) 197 W
Operating relative humidity (H-H) 20 - 80%
Storage temperature (T-T) -10 - 60 °C
Storage relative humidity (H-H) 10 - 90%
Power
Power source AC
Power consumption (standby) 0.5 W
Power consumption (PowerSave) 199 W
AC adapter output voltage 100 - 240 V
AC input frequency 50 - 60 Hz
AC input voltage 100 - 240 V
Packaging data
Package weight 9.15 kg
Package width 450 mm
Package depth 485 mm
Package height 325 mm
Quantity per pack 1 pc(s)
Weight & dimensions
Weight 6 kg
Height 133 mm
Depth 395 mm
Width 356 mm
Packaging content
Remote control included Yes
Cables included AC, USB
Bundled software Easy Interactive Tools, EasyMP Multi PC Projection, Epson Classroom Connect, Epson Projector Management
Batteries included Yes
Network
Ethernet LAN (RJ-45) ports 1
Wi-Fi Yes
Wi-Fi standards 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Ethernet LAN Yes
Ethernet LAN data rates 10, 100
Other features
Option type Air filter, Ceiling mount, Connection and control box, External Speaker, Finger Touch Unit, Finger Touch Unit Wall Bracket, Pen tip(Felt), Pen tip(Teflon), Safety wire set, Visualiser camera, WP System - ELPWP10, Wall mount, Wireless LAN unit, Wireless transmitter - ELPWT01
Control panel 0.62 inch with C2 Fine
Supported network protocols HTTPS, IPv4, IPv6, SNMP, ESC/VP.net, PJLink
Box contents 2 x Pen tip(Teflon), 4 x Pen tip(Felt), Corner markers for auto screen adjustment, Interactive pens, Pen Holder/Stand, Power cable, Projector feet, Quick Start Guide, Remote control incl. batteries, USB cable, Warranty document
Security features Kensington lock, Control panel lock, Password lock, Padlock, Security cable hole, Wireless LAN unit lock, Wireless LAN security, Password protection
Logistics data
Products per pallet 12 pc(s)
Pallet gross length 120 cm
Pallet gross width 80 cm
Pallet gross height 2.1 m
Products per pallet layer 2 pc(s)
Products per pallet layer (UK) 4 pc(s)
Products per pallet (UK) 24 pc(s)
Pallet length (UK) 120 cm
Pallet height (UK) 2.1 m
