Chieftec CSN-650C power supply unit 650 W 20+4 pin ATX SFX Black

113.76 €
Monthly payment from 3,83 €
1968847

CSN-650C

4710713235779

Shipping 11-12 b.d.

You are interested in this product?
(Read terms of service)

All about the product

Chieftec CSN-650C. Total power: 650 W, AC input voltage: 100 - 240 V, AC input frequency: 47 - 63 Hz. Motherboard power connector: 20+4 pin ATX, Cabling type: Fully-Modular. Purpose: PC, Power supply unit (PSU) form factor: SFX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Fan diameter: 8 cm, Number of fans: 1 fan(s). Compliance certificates: RoHS
Power
Efficiency 90%
Input current 6 A
Power protection features Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Power factor 0.9
Power Factor Correction (PFC) type Active
Combined power (+3.3V) 90 W
Combined power (+5V) 90 W
Max output current (+3.3V) 18 A
Max output current (+5V) 15 A
Max output current (+5Vsb) 3 A
Max output current (-12V) 0.3 A
AC input voltage 100 - 240 V
AC input frequency 47 - 63 Hz
Max output current (+12V1) 54 A
Total power 650 W
Performance
ATX version 2.3
Purpose PC
80 PLUS certification 80 PLUS Gold
Power supply unit (PSU) form factor SFX
Design
Product colour Black
Number of fans 1 fan(s)
Fan diameter 8 cm
Ports & interfaces
Floppy drive power connector 1
Number of SATA power connectors 6
Peripheral (Molex) power connectors (4-pin) 3
CPU power connector (4+4 pin) Yes
PCI Express power connectors (6+2 pin) 2
Motherboard power connector 20+4 pin ATX
Cabling type Fully-Modular
Weight & dimensions
Width 125 mm
Depth 100 mm
Height 64 mm
Logistics data
Harmonized System (HS) code 84733020
Certificates
Compliance certificates RoHS
