Fractal Design Venturi HF-14 Computer case Fan 14 cm Black, Grey, White
32.23 €
1897641 FD-FAN-VENT-HF14-WT
7340172700197
Shipping 14-15 b.d.
You are interested in this product?
All about the product
The Venturi High Flow Series fans, HF-12 and HF-14, are optimized for low-restriction airflow environments, making them an excellent choice for computer case fans, or other low-restriction usage scenarios.Designed with a variety of performance-increasing and noise-reducing features, these fans can move an amazing amount of air compared to other fans at the same, minimal noise level.
The HF-14 comes with two sets of solid vibration-dampening rubber corners: one for standard 140mm fan hole spacing (125mm) and one compatible with the standard 120mm hole spacing (105mm). The Venturi High Flow Series fans are ideal for those looking for a perfect balance between high performance and low noise built from sturdy, high quality materials.
- Featuring true FDB-bearings, providing silent operation coupled with a long lifespan
- Equipped with a counter-balanced magnet that reduces the axial tension on the bearing
- Features integrated vibration-dampening corners, made from solid high-quality synthetic rubber
- Dense, sturdy construction, made from high-grade glass fiber reinforced thermoplasticpolymer
- Fan geometry is optimized for a ground-breaking airflow, perfect for low-restriction usage scenarios such as computer case ventilation and low-density heatsinks or radiators.
- Aerodynamically shaped thin stator struts reduce noise and unwanted turbulence
- Strategically placed notches on the blades further reduce and diffuse any humming noise produced when the blades pass the stator struts
- The trip wire technology introduces a micro-turbulent layer that combats elements that negatively affect performance, resulting in quieter operation
- Featuring a powerful motor to maintain a reliable speed and a low-speed adapter for reducing the speed without the use of a fan controller
- 140mm fans come with an additional set of vibration-dampening corners are included that lends compatibility with 120mm fan mounts (105mm screw spacing). This enables the use of 140mm fans on many CPU coolers.
- Available in 120mm and 140mm fan sizes
Performance | |
| Type | Fan |
| Mean time between failures (MTBF) | 150000 h |
| Fan diameter | 14 cm |
| Airflow | 200.8 m³/h |
| Maximum airflow | 118.2 cfm |
| Maximum air pressure | 0.95 mmH2O |
| Noise level (high speed) | 26.5 dB |
| Rotational speed (max) | 1200 RPM |
| Rotational speed with LNA (max) | 850 RPM |
| Airflow with LNA (max) | 133.4 m³/h |
| Noise level with LNA (max) | 18.3 dB |
| Bearing type | Fluid Dynamic Bearing (FDB) |
| Suitable location | Computer case |
Design | |
| Product colour | Black, White, Grey |
| Number of fans | 1 fan(s) |
| Fan connector | 3-pin |
| Number of fan blades | 11 |
Power | |
| Rated current | 0.3 A |
| Voltage | 12 V |
| Starting voltage | 4 V |
Weight & dimensions | |
| Weight | 202 g |
| Package weight | 260 g |
| Height | 140 mm |
| Width | 140 mm |
| Depth | 25 mm |
| Cable length | 0.5 m |
Packaging content | |
| Screws included | Yes |
| Low-noise adaptor (LNA) | Yes |
Other features | |
| Country of origin | Sweden |
