Hismart Refractometer, 0-20% Brix, ATC, handheld sugar meter

Refractometer, 0-20% Brix, ATC
The handheld refractometer is designed to measure the sugar content in fruits and vegetables, wines, and soft drinks. Brix scale 0-20%, reading scale division 0.5%.

Features:
The traditional refractometer is a professional device used to calculate the sugar content in liquids. It is commonly used by winemakers to determine the best harvest time.
It is an optical measuring device that determines the density of a liquid based on its refractive index. Its body is in a simplified telescope shape, with a prism at the back. The eyepiece allows reading data on the Brix scale - this is a measure of dissolved solids in the liquid.
Integrated automatic temperature compensation (ATC range from 10°C to 30°C). When the ambient working temperature changes within these limits, recalibration is not necessary.
The scale measurement allows for direct result reading. Adjustable manual focus.
Manual calibration is supported (mini screwdriver included). Distilled water can be used for calibration: ensure that the ambient temperature is around 20°C, and turn the calibration screw with the screwdriver until the reading shows 0.
Portable, compact, and lightweight: comes with a pipette, screwdriver, and cloth, in a convenient sturdy case.
Wide application: a professional meter for determining sugar content in liquids, food, fruits, beverages, etc. Perfect for home brewing, winemaking, farming, gardening, and educational purposes.

Usage:
1. Open the prism cover and gently wipe the prism with a soft cloth.
2. Use a pipette to take a few drops of the solution to be tested, and place it on the detection prism.
3. Carefully close the prism cover to avoid air bubbles and allow the solution to spread over the prism surface.
4. Point the refractometer towards a light source.
5. Observe the eyepiece and, if necessary, focus to clearly see the scale readings.
6. The dividing line between the blue and white parts of the scale is the reading value, which indicates the concentration of the solution.
7. Keep the refractometer in a dry and clean box to ensure reading accuracy and device durability.


Technical specifications:
Measurement range: 0-20% Brix.
Scale division value: 0.5% Brix.
Accuracy: ±0.5%.
ATC compensation range: 10°C ~ 30°C.
Control temperature: 20°C.
Body material: copper coating, rubber handle.
Color: black.
Weight: 96g.


Warranty: 24 months.
