The product's shade and actual color may differ from what is shown in the picture, as the images are for illustrative purposes. The product description is general and may not include all the product's features.

KMC-20-40 Modular Relay 20 A 400 V AC IDEAL

39,00 €
Monthly payment from 1.90 €
3717190

5905339559623

Shipping 1-14 b.d.

Quantity

You are interested in this product?
(Read terms of service)
Device type : Contactor - NO, Three-phase
Rated load current :
  • 20 A @ AC7A / AC1,
  • 7 A @ AC7B
    • Rated load voltage : 400 V AC
    Rated supply voltage : 230 V AC
    Rated power :
  • 13000 W @ 400 V AC7A
  • 3500 W @ 400 V AC7B
    • Number of normally closed/open contacts : 4 / 0
    Usage category : AC1, AC7A, AC7B
    Type of connections : screw terminals
    Main features :
  • Operating temperature : -25 °C ... 40 °C
  • Compliance with standards : PN-EN 60947-4-1, PN/EN 61095
    • Housing : Plastic, mounting on DIN, TH-35 rail
    Ingress protection class : IP20
    Width in modules 17.5 mm : 2
    Weight : 0.21 kg
    Dimensions : 67 x 82 x 36.2 mm
    Manufacturer / Brand : IDEAL
    Warranty : 5 years
