Shuttle XPС slim XH610G2 PC/workstation barebone
Shuttle XPС slim XH610G2 PC/workstation barebone
Shuttle XPС slim XH610G2 PC/workstation barebone
Shuttle XPС slim XH610G2 PC/workstation barebone
Shuttle XPС slim XH610G2 PC/workstation barebone

The product's shade and actual color may differ from what is shown in the picture, as the images are for illustrative purposes. The product description is general and may not include all the product's features.

Shuttle XPС slim XH610G2 PC/workstation barebone

429,00 €
Monthly payment from 11.95
3288039

XH610G2

0887993006796, 0887993007076

2026-08-07

Quantity
You are interested in this product?
(Read terms of service)
The Shuttle XPC slim Barebone XH610G2 is a 4.7-litre PC with two slots for PCI-Express expansion cards. Together with an LGA 1700 Intel Core desktop processor of the Intel Core Gen 12/13/14 range, this platform is perfectly suited for many professional applications where performance, flexibility and a compact form factor matter. This includes video wall presentations, graphics workstations, media capturing, surveillance, POS, POI as well as network and industrial applications. Even mid-range gaming is possible.

Wi-FiNo
Product colourBlack
HDMI ports quantity2
USB 2.0 ports quantity4
Weight2.98 kg
Width250 mm
Depth200 mm
Height95 mm
AC adapter includedYes
Memory voltage1.1 V
Cooling typeActive
Package weight3.49 kg
Sustainability certificatesENERGY STAR; ErP
Windows operating systems supportedWindows 11
Quick start guideYes
Country of originChina
Operating temperature (T-T)0 - 50 °C
Operating relative humidity (H-H)10 - 90%
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
Microphone inYes
Headphone outputs1
DC-in jackYes
Ethernet LANYes
Ethernet LAN (RJ-45) ports2
LED indicatorsYes
AC input voltage100 - 240 V
Drivers includedYes
Product typePC barebone
Built-in speaker(s)No
On/off switchYes
Audio output channels7.1 channels
AC input frequency50/60 Hz
HDMI version2.0b
Power supply typeExternal AC adapter
Linux operating systems supportedYes
NVMeYes
VGA (D-Sub) ports quantity0
Power supply180 W
Built-in processorNo
Processor manufacturerIntel
Maximum internal memory64 GB
On-board graphics cardYes
Chassis typeDesktop
Motherboard chipsetIntel H610
Trusted Platform Module (TPM)Yes
DisplayPorts quantity1
DisplayPort version1.4
Harmonized System (HS) code84733080
Processor socketLGA 1700
LAN controllerIntel® I219-LM; Intel I226-LM
Audio chipRealtek ALC888S
Number of processors supported1
Supported memory typesDDR5-SDRAM
Non-ECCYes
Storage drive sizes supported2.5; M.2
Supported storage drive typesHDD & SSD
Trusted Platform Module (TPM) version2.0
BIOS typeUEFI AMI
Number of memory slots2
Memory slots typeSO-DIMM
Memory channelsDual-channel
AC adapter output voltage19.5 V
AC adapter output current9.23 A
Storage drive interfaceSerial ATA III; PCI Express
Supported memory clock speeds5600 MHz
Power cord includedYes
Compliance certificatesCE; RoHS; Federal Communications Commission (FCC); UKCA; VCCI; BSMI; CB; RCM; cTUVus
