TP-Link LiteWave 5-Port Gigabit Desktop Switch with 4-Port PoE+
TP-Link LiteWave 5-Port Gigabit Desktop Switch with 4-Port PoE+
TP-Link LiteWave 5-Port Gigabit Desktop Switch with 4-Port PoE+
TP-Link LiteWave 5-Port Gigabit Desktop Switch with 4-Port PoE+

The product's shade and actual color may differ from what is shown in the picture, as the images are for illustrative purposes. The product description is general and may not include all the product's features.

TP-Link LiteWave 5-Port Gigabit Desktop Switch with 4-Port PoE+

30,79 €
3038086

LS105GP

4895252504545, 4895252504552

2026-07-27

Quantity
You are interested in this product?
(Read terms of service)
Overview
The TP-Link LiteWave Series PoE Switches require no configuration and provide PoE (Power over Ethernet) ports. They can automatically detect and supply power with all IEEE 802.3af/at compliant Powered Devices (PDs). In this situation, the electrical power is transmitted along with data in one single cable allowing you to expand your network to where there are no power lines or outlets, where you wish to fix devices such as APs, IP Cameras or IP Phones, etc.
Product colourBlack
Width99.8 mm
Depth98 mm
Height25 mm
Package typeBox
CertificationCE, FCC, RoHS
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-40 - 70 °C
Operating relative humidity (H-H)10 - 90%
Networking standardsIEEE 802.3ab; IEEE 802.3u; IEEE 802.3af; IEEE 802.3at; IEEE 802.3x; IEEE 802.1p; IEEE 802.3i
Auto MDI/MDI-XYes
LED indicatorsYes
AC input voltage220 V
Power sourceDC/PoE
AC input frequency50 Hz
Power consumption (max)74.46 W
Storage relative humidity (H-H)5 - 90%
Power over Ethernet (PoE)Yes
Power over Ethernet (PoE) ports quantity4
Total Power over Ethernet (PoE) budget65 W
10G supportNo
User guideYes
Switch typeUnmanaged
Quality of Service (QoS) supportYes
Basic switching RJ-45 Ethernet ports quantity5
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Flow control supportYes
MAC address table2000 entries
Switching capacity10 Gbit/s
Jumbo frames16000
IGMP snoopingYes
DC input voltage53.5 V
Power over Ethernet (PoE) power per port30 W
Forwarding rate7.44 Mpps
Store-and-forwardYes
Power supply includedYes
Heat dissipation253.16 BTU/h
Cable types supportedCat5; Cat5e; Cat3; Cat4
Auto-negotiationYes
Installed SFP modules quantity0
Installed SFP+ modules quantity0
MAC address auto-learning supportedYes
MAC address auto-aging supportedYes
