Alfa SHORT - FAAC 414 kit for 6m double-leaf gates
2851490 28247
8055195065497
Shipping 1-14 b.d.
The drive FAAC-ALFA-SHORT/KIT is intended for swing gates, where the length of one frame is 1.8 m.
Thanks to many technological improvements, the device is safe and convenient to use.
There is no need to install locks in the drive (self-locking).
For example, in the event of a power outage, a simple gearbox mechanism in the drive allows the door to be operated manually.
W zątewie znało się: 2 actuators (cylinders) - model 414 SHORT, controller E045S, photocell kit XP20BD (transmitter + receiver pair), radio communication module XF868, radio remote control XT4, 2 emergency release keys, controller housing - model E and required installation accessories.
| Gate drive type : | Mechanical, for swing gates - a set of double-door gates |
| Maximum pulling force : | 3500 N |
| Engine type : | Asynchronous single-phase motor, 230 V AC |
| Maximum gate length : | 1.8 m (Single gate) |
| Linear speed : | 16 mm/s (max) |
| Rotation angle : | 110° (max) |
| Automatic gate closing : | ✔ |
| Automatic gear lock : | ✔ |
| Limit Switch : | ✔ |
| It is possible to connect a photocell : | ✔ |
| A signal lamp can be connected : | ✔ |
| Maximum number of programmed pilots : | 250 Channels |
| Wireless transmission distance : | ≥ 50 m (in open space) |
| Frequency band working systems : | 868.35 MHz |
| Number of cycles per hour : | ≤ 18 |
| Main features : | Self-braking gear The kit includes mounting brackets: rear bracket (to strut) to be welded and/or bolted front bracket (to sash) to be welded The controller body is included |
| Meals : | 220 ... 240 V AC , 50 / 60 Hz |
| Body : | Plastic + Metal (gears 414 SHORT) Plastic (controller body) |
| Sealing class : | IP44 (actuators 414 SHORT) IP55 (controller housing) |
| Color : | Black (actuators 414 SHORT) Light gray (controller body) |
| Working temperature : | -20 °C ... 55 °C |
| Weight : | 5.6 kg (single gate drive) |
| Dimensions : | 991 x 101 x 172 mm (single gate drive) 265 x 205 x 87 mm (controller body) |
| Manufacturer / Brand : | FAAC |
| Warranty : | 2 years |
