Zotac ZBOX edge MI648 0.64L sized PC Black i5-1340P 1.9 GHz
589,00 €
Monthly payment from 16.07 €
2372982 ZBOX-MI648-BE
4895173627880
2026-07-30
You are interested in this product?
The ZBOX edge MI648 boasts an award-winning design, and features an ultra-thin enclosure powered by an Intel Core i5 processor. With efficient thermal design, power management, and plenty of open ventilation, the ZBOX edge MI648 still maintains a remarkably low-profile design and a full set of I/O connectivity. Overall, this is an excellent gateway for efficient edge computing or everyday computing tasks in business, office, or home settings.
LIGHTWEIGHT PERFORMANCE
Introducing the ZBOX edge MI668/MI648, mini PCs that deliver essential performance in a lightweight package. Whether it’s the home, office, or on the go, this palm-sized Mini PC series carries the hardware that excels in a wide range of productivity and entertainment scenarios.
POWERFUL AT ITS THINNEST
At only 28mm (1.12 inches) thin, the ZBOX edge MI668/MI648 offers both impressive performance and a cleaner desk. Despite its compact 0.64-liter system size, the ZBOX edge comes equipped with a versatile array of ports and connectivity options for every occasion.
DO MORE, FASTER
The ZBOX edge features an Intel® Core™ Processor with up to 12 cores and DDR5 memory, making it a lightweight champion of everyday computing, multitasking, media serving, or even surveillance and home automation.
STUNNING VISUALS
Featuring integrated Intel Iris® Xe® Graphics, the ZBOX edge has quite the graphical chops. Take your productivity to the next level with multiple displays, immerse yourself in 4K entertainment, or even some light gaming. The versatility of the ZBOX edge is only matched by its graphical prowess.
CONNECTIVITY AT ITS BEST
A practical array of connectivity options are included in the ZBOX edge Mini PCs. With Dual Gigabit Ethernet, WiFi 6, and Bluetooth 5.2, expect fast internet access for online and cloud applications; for connecting other devices and transferring large amounts of data, the USB 3.1 and Thunderbolt 4 port with up to 40GBps data bandwidth come in handy.
CONNECTIVITY SUITE
Equipped with a full range of I/O, the ZBOX edge has everything you need as your daily driver.
WHISPER QUIET
The ZBOX edge features a wide ventilation design for increased airflow and a Smart Fan for rapid heat dissipation so that it is always quiet and cool to the touch.
HONEYCOMB VENTS
A wide degree of ventilation maximizes airflow in the low-profile chassis to enable more sustained CPU and GPU performance.
HIGHER CAPACITY
Support for a total of up to 64GB of DDR5 5200MHz memory and up to 2 x M.2 SSDs ensure more storage capacity, lower latency, and snappier operation for your ZBOX edge system.
EASILY UPGRADEABLE
Access the internals in just a few steps, and easily install or update the ZBOX edge Mini PC with up to 2 x M.2 SSDs and up to 64GB DDR5 Memory.
NIMBLE VERSATILITY
The M Series edge is slim enough to fit in the tightest of spaces. With the included VESA mount, there are limitless options for its placement.
MEET ALL COMPUTING NEEDS
ZBOX edge is the thinnest solution that makes a perfect gateway for IoT-enabled applications, daily tasks, and remote management.
| Wi-Fi | Yes |
| Product colour | Black |
| HDMI ports quantity | 1 |
| Processor frequency | 1.9 GHz |
| Processor family | Intel® Core™ i5 |
| Processor model | i5-1340P |
| Processor cores | 12 |
| Wi-Fi standards | Wi-Fi 6 (802.11ax) |
| Width | 149.5 mm |
| Depth | 149.5 mm |
| Height | 28.5 mm |
| AC adapter included | Yes |
| Cooling type | Passive |
| Quick start guide | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| Microphone in | Yes |
| Headphone outputs | 1 |
| DC-in jack | Yes |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 2 |
| Card reader integrated | No |
| Drivers included | Yes |
| Built-in speaker(s) | No |
| On/off switch | Yes |
| HDMI version | 2.0 |
| Power supply type | External AC adapter |
| Thermal Design Power (TDP) | 28 W |
| SSD form factor | M.2 |
| Power supply | 40 W |
| Built-in processor | Yes |
| Processor manufacturer | Intel |
| Processor cache | 12 MB |
| Maximum internal memory | 64 GB |
| On-board graphics card | Yes |
| On-board graphics card model | Intel Iris Xe Graphics |
| Chassis type | 0.64L sized PC |
| DisplayPort version | 1.4 |
| Processor threads | 16 |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Supported memory types | DDR5-SDRAM |
| Storage drive sizes supported | M.2 |
| Supported storage drive types | SSD |
| Number of memory slots | 2 |
| Memory slots type | SO-DIMM |
| AC adapter output voltage | 19 V |
| Number of power supply units | 1 |
| Storage drive interface | Serial ATA; PCI Express |
| Supported memory clock speeds | 4800; 5200 |
| Power cord included | Yes |
| Graphics card family | Intel |
| Performance cores | 4 |
| Efficient cores | 8 |
| Performance-core boost frequency | 4.6 GHz |
| Efficient-core boost frequency | 3.4 GHz |
| Thunderbolt 4 ports quantity | 1 |
| Processor generation | 13th gen Intel® Core™ i5 |
