Satel AQUA Ring S Infrared sensor Wired Ceiling White

The product's shade and actual color may differ from what is shown in the picture, as the images are for illustrative purposes. The product description is general and may not include all the product's features.

Satel AQUA Ring S Infrared sensor Wired Ceiling White

59,00 €
27,90 €
1947407

5905033335400

5905033335400

Shipping 2-3 b.d.

Quantity
You are interested in this product?
(Read terms of service)
AQUA Ring S is a digital passive infrared detector in oval enclosure, designed for ceiling mounting. It is ideally suited for use in locations where wall mounting is difficult or just impossible, for example, in rooms with fully glazed walls or showcases. It can also be used in spacious premises, because its design allows protection of a large area. AQUA Ring S is provided with a dual element PIR sensor and digital motion detection algorithm, and that's why it is characterized by good immunity to interference and false alarms. Three-step sensitivity control makes it possible to adjust the device performance to requirements of the user and the protected premises. The detector has a built-in pre-alarm feature and tamper switch to protect it against opening the enclosure. The detector is powered from a 24 V DC or AC source, so it can be installed in systems running on 24 V (instead of the standard 12 V) voltage.

The main task of the detector is to detect violations in the protected area. However, it can also be used to implement the building automation functions. When the alarm system is not armed, the detector can control turning on the lights, opening or closing the doors, etc.
Product colourWhite
Weight64 g
Width97 mm
Depth97 mm
Height29 mm
Connectivity technologyWired
Operating temperature (T-T)-30 - 55 °C
Input voltage24 V
Mounting typeCeiling
Sensor typeInfrared sensor
Standby current40 mA
